31
If your dishwasher came with a plastic toe panel (L) and slotted toe panel
(M) follow these instructions:
Note: If using the plastic toe panel shown in 31 above, then metal mounting
brackets shown in 28 are not required.
• Align the plastic toe panel on the base of the dishwasher so the holes
line up.
• Attach using screws (H) as shown. Use only the supplied screws to
avoid damaging the dishwasher.
• Slide metal toe panel into position ensuring the bottom of the toe
panel is flush with the floor. Your installation is complete!
27
28
H
L
H
M
