Cleaning and maintenance en-us
25
8. Insert the filter system into the appliance and turn the
coarse filter clockwise.
Make sure that the arrow markings match up.
9. The spray arm will automatically return to the correct
position when starting, so it’s not necessary to
reposition the spray arm to the front.
15.5 Cleaning spray arms
Limescale and debris in the dishwashing water may block
the nozzles and bearings on the spray arms. Clean the
spray arms regularly.
1. Unscrew the upper spray arm and pull down to
remove .
2. Check that the lower spray arm is at the 6 o'clock
position.
3. Hold the spray arm in the center and lift straight up to
remove.
4. Check the outlet nozzles on the spray arms for
blockages under running water and remove any foreign
objects.
5. Reinsert the lower spray arm by first setting it in the 6
o'clock position, then push down until it clicks.
6. Insert the upper spray arm and screw firmly in place.
