en-us Familiarizing yourself with your appliance
8
4
Detergent tab collecting tray During the wash cycle, detergent tabs automatically drop out of
the detergent dispenser into the tab collecting tray, where they
can dissolve fully.
5
Upper rack
Upper rack → Page12
6
Silverware drawer
Silverware drawer → Page13
7
Cup shelf
1
Cup shelf → Page14
8
Upper spray arm The upper spray arm washes the dishware in the upper rack.
If the dishware has not been washed properly, clean the spray
arms.
9
Intake opening of the Zeolith container
The intake opening is required for Zeolith drying → Page6 .
10
Blow opening of the Zeolith container
The blow opening is required for Zeolith drying → Page6 .
11
Filter system
Filter system → Page24
12
Silverware basket Silverware basket
13
Dispenser for rinse aid Rinse aid is added to the dispenser for rinse aid.
→ "Rinse aid system", Page15
14
Rating plate
Rating plate with E number and FD number → Page35 .
You will need this data to contact Customer service → Page35 .
1
Depending on the appliance specifications
4.2 Controls
You can use the control panel to configure all functions of your appliance and to obtain information about the operating
status.
1 2 3 4 5 6 7
8A 9
A
Button If you press for approx. 3 seconds, you can open the
basic settings.
→ "Changing the basic settings", Page22
1
ON/OFF button and reset button Switching on the appliance
Switching off the appliance
Terminating the wash cycle → Page20
