Technical data
9
6 720 891 048 (2019/01)
3 Technical data
* Larger cable cross-sections may be required depending on the
connection configuration.
** The pressure loss on the mixer must also be added.
3.1 Solar heated
Only for appliances that are suitable for solar heating systems:
The appliance can only heat prewarmed water to a max. of 60 °C.
If the cold water supply exceeds a temperature of 55 °C, the water will
not be warmed any further.
Important: The cold water supply temperature must not be higher
than 55 °C!
If the cold water supply exceeds a temperature of 60 °C, a circuit breaker
will trigger and shut the appliance off. Therefore, the residential
plumbing must be equipped with a thermostatic premixer (e. g. special
accessory BZ 45T20) that will limit the cold water supply temperature
to a max. of 55 °C by appropriately mixing in cold water.
Dimensions (Fig. 9)
4 Special accessories
• Pipe kit BZ 45U20 for use of the appliance as an under-sink
appliance
• Priority switch (load shedding relay) BZ 45L21:
for operation with a priority circuit
• Mounting kit BZ 45K23: for surface mount installation
• Only for appliances that are suitable for solar heating systems:
Thermostatic premixer BZ 45T20: for installation in the domestic
plumbing when using preheated water
5 Environmental protection/disposal
Environmental protection is a fundamental corporate strategy of the
Bosch Group.
The quality of our products, their economy and environmental safety are
all of equal importance to us and all environmental protection legislation
and regulations are strictly observed.
We use the best possible technology and materials for protecting the
environment taking account of economic considerations.
Packaging
Where packaging is concerned, we participate in country-specific
recycling processes that ensure optimum recycling.
All of our packaging materials are environmentally compatible and can be
recycled.
Used appliances
Used appliances contain valuable materials that can be recycled.
The various assemblies can be easily dismantled. Synthetic materials are
marked accordingly. Assemblies can therefore be sorted by composition
and passed on for recycling or disposal.
Used electrical and electronic appliances
Electrical or electronic devices that are no longer
serviceable must be collected separately and sent for
environmentally compatible recycling (in accordance with
the European Waste Electrical and Electronic Equipment
Directive).
To dispose of old electrical or electronic devices, you
should use the return and collection systems put in place in the country
concerned.
Batteries must not be disposed together with your household waste.
Used batteries must be disposed of in local collection systems.
TR5000R 18/21
EAB
TR5000R 24/27
EAB
TR7000R 18/21
DESOAB
TR7000R 24/27
DESOAB
Rated output [kW] 15/21 21/27 15/21 21/27
Rated voltage [V] 400 400 400 400
Fuse protection [A] 32 40 32 40
Minimum conductor cross-section* [mm
2
] 4 6 4 6
Warm water flow at rated output
with temperature increase from
12 °C to 38 °C (without flow-rate limiter)
12 °C to 38 °C (with flow-rate limiter)
12 °C to 60 °C
[l/min]
[l/min]
[l/min]
9.8/11.6
7.6
5.3/6.2
13.0/14.6
9.3
7.1/7.9
9.8/11.6
7.6
5.3/6.2
13.0/14.6
9.3
7.1/7.9
Start-up flow [l/min] 2.5 2.5 2.5 2.5
Start-up flow pressure** [MPa (bar)]
0.04
0.4
0.04
0.4
0.04
0.4
0.04
0.4
Application area in water
specific electric resistance at 15 °C
[Ωcm] ≥ 1 300 ≥ 1 300 ≥ 1 300 ≥ 1 300
Rated pressure [MPa (bar)] 1.0 (10) 1.0 (10) 1.0 (10) 1.0 (10)
Maximum permissible supply temperature [°C] 20 20 55 55
Maximum mains impedance at connection point [Ω] 0.067/0.104 0.067/0.104 0.067/0.104 0.067/0.104
Energy efficiency class A A A A
Load profile SSSS
Annual energy consumption [kWh] 479 479 479 479
Daily energy consumption [kWh] 2.203 2.207 2.203 2.207
Sound power level [dB] 15 15 15 15
Hot water heating energy efficiency [%] 38.5 38.5 38.5 38.5
