Bosch High Performance HD LED Monitors Table of Contents | en 3
Bosch Security Systems, Inc. User's Manual F.01U.134.499 | 2.0 | 2012.10
Table of Contents
1Safety 5
1.1 Important safety instructions 5
1.2 Safety precautions 7
1.3 Important notices 7
1.4 Customer Support and Service 12
2 Unpacking 13
2.1 Parts List 13
3 Access and Connections 14
3.1 Front Control Panel 14
3.2 Rear Panels 14
3.3 Bottom Panel 16
3.4 Remote Control 17
3.5 Remote Control Battery Installation 17
4 Description 19
4.1 Features 19
4.2 Power 19
5 Installing the Monitor 20
5.1 Ventilation 20
5.2 Desktop Installation 20
5.3 Mounting the Monitor to a Wall 21
5.4 Connecting Power 22
5.5 Connecting the Composite Video Signal to the Monitor 22
5.6 Connecting the Y/C (S-Video) Signal to the Monitor 23
5.7 Connecting Audio to the Monitor 23
5.8 Connecting the PC Signal to the Monitor 23
5.8.1 HDMI Connection 23
5.8.2 DVI Connection 23
5.8.3 VGA Connection 23
5.9 Connecting an Alarm Trigger 24
5.10 Single / Multiple Monitor Configuration 25
6 Navigating the Monitor 27
6.1 Navigating the Control Panel 27
6.2 Using the Monitor On-screen Display (OSD) 27
6.3 On-screen Display Menus 28
6.4 Picture Menu 28
6.5 Sound Menu 29
6.6 Option Menu 30
6.6.1 PIP Availability 31
6.7 Setting Menu 31
