Bosch Security Systems | 2004-06
| 57
8637 & 8638 | Installation Instructions
Technical specification
Specifications may be changed without notice.
CCD CAMERA
Installation Instructions
Pick-up device 1/3" (Solid state CCD)
No. of picture elements
(H) x (V) 512 x 492 (EIA)
512 x 582 (CCIR)
Horizontal resolution > 380 TVL
Light sensitivity 0.5 - 30000 lux
Spectral sensitivity range 400 ~ 1000 nm
Signal to noise ratio > 48 dB
Output A/V RJ 11 E modular ‘telephone’ socket
Built-in microphone electret
Lens type integrated
Lens viewing angle 59°H x 46ºV
• focal length 4 mm
• relative aperture F 2.0
•focus range 1∼ ∞ m
Power supply 16 - 27V
DC (via system cable)
Power consumption 50 mA (at 24V
DC)
System cable 4-wire dual twisted pair cable e.g.
VSS2906/00 or VSS2930/00
Tripod socket 1/4" B.S.W.
Dimensions (WxHxD) 70 x 70 x 79 mm (incl. lens)
Weight 205 gr
Ambient conditions Ammonia resistant
Ambient temperature
• operating +10ºC ~ +55ºC
• storage -25ºC ~ +70ºC
Ambient humidity
• operating 20% - 90%RH
•storage 99%RH
