5. If bubbles form around the brass connector or on the gas valve
itself, replace the leaking valve with a new one and repeat
steps 3, 4 and 6.
6. Clean all soapy water solution with a rag or paper towel.
7. Never use a flame to check for gas leaks!
4.1.6 Igniter
Igniters glow after
4.1.7 Flame sensor
Flame sensors detect flame out in 30 – 60 seconds and direct the
igniter to reignite flames.
4.1.8 Lint screen sensors
The front (bearing) shield contains two sensors – accessible after the
lint screen is removed. Along with the heater NTC and hi-limit
protector, the lint screen NTC and hi-limit protector provide
temperature regulation and safety.
30 seconds, reliably igniting gas flames.
Igniters can be damaged if not handled with care.
Hi-limit NTC
Hi-limit
NTC
702_58300000143767_ara_en_a Page 8 of 33
