Bose 3-2-1 Service Manual

8
PACKAGING PART LIST
321 Home Entertainment System Packaging View (see Figure 1)
PART LIST NOTES
1. This part is not normally available from Customer Service. Approval from the Field Service
Manager is required before ordering.
2. The individual parts located on the PCBs are listed in the Electrical Part List.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire
and/or other hazards.
Item
Number
Description Part Number Note
1 COMMITMENT LETTER 251001
2 SHT, QUICKSTART, MULTI-LANGUAGE 267520
3 MANUAL, OWNERS, 3 LANG
MANUAL, OWNERS, 5 LANG
256951
256952
4 CARD, INFO, WARRANTY, MULTI LANG 181460
5 CARD, REPLY 3.2.1 (US, DUAL) 268158
6 ADDRESS PAGE, BOSE 259434
7 BAG, POLY, 14.38 x 9.87 x 2 mil 103351
8 PACKING, EPS, CONSOLE 263123
9 ACCY KIT, 3.2.1, 230V, GRPHT (EURO, UK)
ACCY KIT, 3.2.1, 100V, GRPHT (JAPAN, AUS, DUAL)
260094-021
260094-001
10 CONSOLE ASSY, 120V, GRPH, RGN 1, (US/CAN)
CONSOLE ASSY, 115/230V, GRPH, RGN 4, (DUAL)
CONSOLE ASSY, 230V, GRPH, RGN 2, (EURO)
CONSOLE ASSY, 230V, GRPH, RGN 2, (UK)
CONSOLE ASSY, 230V, GRPH, RGN 3, (S.E. ASIA)
CONSOLE ASSY, 230V, GRPH, RGN 4, (AUS,S. AMER)
CONSOLE ASSY, 230V, GRPH, RGN 5, (AFRICA, RUSS)
CONSOLE ASSY, 230V, GRPH, RGN 6, (CHINA)
CONSOLE ASSY, 100V, GRPH, RGN 2, (JAPAN)
CONSOLE ASSY, 115/230V, GRPH, RGN 2, (DUAL)
256960-111C
256960-114C
256960-212C
256960-2123
256960-213C
256960-214C
256960-215C
256960-216C
256960-312C
256960-612C
1, 2
11 PACKING, INSERT, EPS, BASS BOX 260091
12 BAG, POLY, 13.5 x 35 x 9.5 x 2.5 mil 114522
13 ASSY, BASS BOX, 120V, GRPH (US/CAN)
ASSY, BASS BOX, 230V, GRPH (EURO, UK, AUS)
ASSY, BASS BOX, 100V, GRPH (JAPAN)
ASSY, BASS BOX, 115/230V, GRPH (DUAL)
255199-1109
255199-2109
255199-3119
255199-6109
1, 2
14 ARRAY ASSEMBLY (W/GRILLE), GRAPHITE 255198-001
15 CARTON, RSC, PRINTED 255183-01
16 LINE CORD, 120V, POL, DET, BLK (US/CAN, DUAL)
LINE CORD, 230V, DETACH, 96" (EURO)
LINE CORD, 220V, DETACH (UK)
LINE CORD, 240V, DETACH (AUS)
LINE CORD, 100V, POL, DET, BLK (JAPAN)
260082-001
148203
134725
134726
260086-001
3
- PACKING, EPS, CONSOLE 254576
- DECLARATION OF CONFORMITY 255192
-
DVD PACK, 3·2·1 IN-BOX (US, DUAL)
269252
