Bose 301 Series Service Manual

9
301
®
Series IV Main Assembly Parts List (Figure 3)
Item
Number
Description Part Number Qty.
Per
Speaker
Reference
1 Grille Assembly, Front:
Brown/Grey or
Black
181851-01
181851-00
1
1
2 Nameplate, Logo:
Large or
Small
122812-0
185208-01
1
1
3 Grille Assembly, Side:
Dark Brown or
Black
181856-01
181856-00
1
1
4 Tweeter, 3" Gasket Backed 266161 1 11/4/2002
5 Grommet, Grille Socket 176068 2
6 Screw, Machine, 8-32 x .375, HexW, Hex 121441-06 2
7 Batting, Polyester, 12 x 2 116082 1 See Note
8 Gasket, Woofer, 8" 187395-208 1
9 Woofer Assembly, 8" 181870-001 1
10 Connector, Barrier, 2 Position 181865 1
11 Screw, Tapp, 8-11 x .75, Pan 172672-12 4
12 Tweeter, 2", Gasket Backed 181862-S P 1 10/1/2002
