Bose 301 Series Service Manual

10
301
®
Series IV Crossover Parts List (Figure 3)
301 Series IV Main Packaging Parts List (Figure 4)
Item
Number
Description Part Number Qty.
Per
Carton
Reference
1 Owner's Manual 181869 1
2 List, Warranty Service Stations 122766 1
3 Card, Info, Warranty, Multi Language 181460 1
4 Card, Info, Warranty, U.S. 181357 1
5 Brochure, All Products 141478 1
6 Bumper, Foot, Adhesive Backed, 8-ct 173012-08 1
7 Polybag, 14.38 x 9.87 x 2 mil 103351 1
8 Packing, Corner Post Set 181867 2
9 Polybag, 13.5 x 35 x 9.5 x 2.5, 5 mil 114522 2
10 Carton, RSC 181868-01 1
Symbol
or Item
Number
Description Part Number Qty.
Per
Speaker
Assy.
See
Note
C1 Capacitor, 4.5uF, 50V, 10%, Elect. 131428 1
C2 Capacitor, 22uF, 50V, 10%, Elect. 184956 1 1
RT1 Lamp, Green dot 141989 1
A Connector, Terminal, Wirewrap 181864 1 2
B Tape, Foil 103597 3" 2
Notes:
1. C2 is mounted to the surface of the woofer basket using foam tape P/N 118223.
2. This part is not normally stocked as a service part.
