17
Satellite Procedures
NOTE: Refer to Figure 7 for an exploded view of
the satellite. Certain parts will be referred to in
these procedures. The item number which
corresponds to the part will be enclosed in
parentheses-i.e.-grille (3).
1. Grille Removal
A. Grasp the top and bottom of the grille and
grille frame (3,5). Pull the assembly carefully
away from the satellite.
2. Grille Replacement
A. Align the grille feet (not shown) with the 4
holes in the satellite enclosure. Push the
assembly gently into place.
3. Twiddler Removal
A. Remove the 4 screws (7) holding the twiddler
(6) in place. Lift the twiddler out and cut the wires
connected to the twiddler as close to its terminals
as possible.
4. Twiddler Replacement
A. Strip the wires and connect to the replacement
twiddler (6).
NOTE: The positive (+) terminal of each twiddler
is marked with a red dot.
B. Connect the red wire to the positive (+)
twiddler terminal and the black wire to the
negative (-) twiddler terminal.
C. Lower the twiddler into the satellite enclosure
and secure the twiddler to the enclosure with 4
screws (7). Repeat the satellite test procedures.
5. Terminal Cover Removal
NOTE: There are catches on the top and bottom
(inside) of the terminal cover (10) that hook it into
the satellite enclosure. Take care when removing
the cover.
A. Using your fingers or a flat blade
screwdriver,pull the terminal cover carefully from
the satellite enclosure using the recesses in the
cover.
6. Terminal Cover Replacement
A. Snap the terminal cover (10) carefully into
place on the satellite enclosure.
7. Guillotine Connector Removal
A. Remove 2 screws (7) which hold the
connector (9) in place.
8. Guillotine Connector Replacement
A. Secure the connector (9) to the satellite
enclosure with 2 screws (7).
