28
Bass Module Packaging Parts List (Figure 5)
Item
Number
Description Part Number Qty.
Per
Carton
See Note
1 Bracket-Wall Mount,Black 145553-01 1
2 Volume Control-Arctic White
(US)
Volume Control-Arctic White
(Eur.)
135209-2
170245-01
1
1
- Polybag (Volume Control) 143393 1
3 Insert-Diecut,Freespace 149240 1
4 Literature Kit-120V 146091-1 1
Literature Kit-230V 146091-2 1
Literature Kit-100V 146091-3 1
which consists of:
A Owner's Manual 145549 1 8
Owner's Manual (Eur.) 149629 1 8
B Warranty Card (US) 139610 1
Warranty Card (Eur.) 135970 1
C Polybag (Literature Kit) 103351 1
D Warranty Service List (US) 122766 1
E Envelope-Warranty Registration (US) 123001 1
Envelope (Eur.,Japan) 128450 1
F Wrench-Allen, 3/16" 145726 1
G Clip-U,1/4-20 145728 2
H Screw-Mach.,1-1/4",Socket Hd. Cap 145767-20 2
5 Packing-End Cap,EPS 139955 4
6 Polybag (Module) 137847 1
7 Carton 145531 1
