Panel Assembly Parts List (Figure 6)
30
Item
Number
Description Part Number Qty.
Per
Assembly
See Note
1 Heatsink 145536 1 1
2 Gasket-Heatsink 145537 1
3 Panel-Mounting,Rear 144495-01 1 1
4 Screw-
Thrd. Form,PAN,4-20 x 3/8"
139761-06 15
5 Connector-Barrier Strip,3P 145543-3 1
6 Gasket-Barrier Strip,3 Term. 145544 1
7 Screw-
Tapp,6-32 x 3/4, PAN, XREC
146093-12 2
8 Transformer-Keep Alive,
EI41/120V,T1 (US,Japan)
145527 1 6
Transformer-Keep Alive,
EI41/220V,T1 (Eur.)
146977 1 6
9 Nut-KEP, #4-40 118260-04 2
10 Switch-Rocker, SPST, 11A 145541 1 3
11 PCB Assembly-I/O 145546 1 1,9
12 Nut-Hex,STND.,Washer,KEPS 118260-08 2
13 PCB Assembly-Main 145524 1 1,9
14 Screw-
Mach.,#6-32 x 5/16,PAN,XREC
146092-05 9
15 Cable Assembly-Volume Control 145539 1
16 Cable Tie 135540 3
17 Fuse
-
Slo-Blo,2.5A,5 x 20mm,
UL,FS1 (US,Japan)
143668-2500
1 6
Fuse-Slo-Blo,1.6A,5 x 20mm,
VDE,FS1 (Eur.)
140346-1600
1 6
18 Nut-Hex, #8-32, Steel 103237-832 1
!
!
!
To Next Page
