Bose FreeSpace DS 100SE Service Manual

19
Figure 6. FreeSpace
®
DS 100SE Surface Mount Speaker Wiring Diagram
Figure 7. FreeSpace DS 100F Flush Mount Speaker Wiring Diagram
100W
50W
25W
NC
1
6
5
4
3
2
A
8 ohm
COM
70.7/100V
5.25 INCH SPKR
SW. ROTARY 1P6T ST-700
NC
100W
50W
25W
70.7V 100V
0 V
WIRE W/110 UL1007 #20 BLUE 300mm
+
_
#18AWG TWIN BL/BK 250MM
WHITE
YELLOW
BLUE
C1
L1
P1
VIN+
C2
CE 100V 10U 10% RL 18x38
P3
LPF+
P4
LPF-
P5
HPF-
P6
HPF+
2.25 INCH SPKR
P5'
HPF-
P6'
HPF+
INDUCTOR 2.2MH 2.5%
P3'
LPF+
P4'
LPF-
P1'
VIN+
P2
VIN-
P2'
VIN-
T1
TRANS AUDIO 70.7/100V IN
12/25/50/100W O/P 8OHM
WIRE-CONN 1P #18 UL1007
70.7V/100V IN
CE 100V 15U 10% RL 16X38
INPUT TERMINAL
TERMINAL OUT PUT
TERMINAL OUT PUT
CROSSOVER PCB SECTION
0V
#18AWG TWIN RED/BK
THERMAL FUSE RATED 100C
UL1015 AWG#18 WHITE
TERMINAL-CERAMIC BLOCK
250V 10A 600C TC-613A
+
-
LAMP1
GREEN DOT LAMP
PTC1
POLYSWITCH REXF050
100W
50W
25W
12W
6
1
2
3
4
5
A
8 ohm
COM 70.7/100V
5.25INCH SPKR
SW. ROTARY 1P6T ST-700
NC
100W
50W
25W
70.7V
100V
0 V
WIRE W/110 UL1007 #20 BLUE 300mm
+
_
TO BRACKET
( WIRE-CONN 4P P3.96 #18UL1007 L=152 VW-1)
WHITE YELLOW
BLUE
2.25 INCH SPKR
2.25 INCH SPKR
P7'
HPF-
P8'
HPF+
P3'
LPF+
P4'
LPF-
P1'
VIN+
P2'
VIN-
T1
TRANS AUDIO 70.7/100V IN
12/25/50/100W O/P 8OHM
WIRE-CONN 1P #18 UL1007
70.7V/100V IN
#18AWG TWIN RED/BK
#18AWG TWIN BL/BK 480MM
C1
L1
P1
VIN+
C2
20UF 100V 10% RL 16X38
P3
LPF+
P4
LPF-
P7
HPF-
P8
HPF+
INDUCTOR 3MH 2.5% DCR=
P2
VIN-
0.5 OHM 10% 38x40 MAX
CE 100V 18U 10% RL 16X38
TERMINAL OUT PUT
TERMINAL OUT PUT
CROSSOVER PCB SECTION
+
_
+
_
P5'
HPF-
P6'
HPF+
P5
HPF-
P6
HPF+
TERMINAL OUT PUT
LAMP1
RED DOT LAMP
BLK.
RED.
GRN.
BLU.
YEL.
WHT.
VOL.
