PACKAGING LIST
FreeSpace
®
DS 100SE Loudspeaker
Figure 1. FreeSpace DS 100SE Packaging View
1
2
3
42x
5
6
7
Item
Number
Description Bose
®
Part
Number
Vendor Part
Number
Qty. Note
1 CARD, INSTALLATION - 3050-4481+0 1 4
2 OWNER’S MANUAL 300289 4301-7260+1 1
3 POLY BAG - 1497-4972+0 1 4
4 FOAM, POLY 299568 1490-4631+0 2
5 BRACKET, WALL MOUNT, BLK 315824-001S 4155-3411+0 1
BRACKET, WALL MOUNT, WHT 315824-002S 4155-3412+0
6 CARTON 299567 1437-8801+0-2
1
7 BAG, BUBBLE - 1497-2812+0 1 4
