TECHNICAL INFORMATION
Mechanical
Dimensions
• L1 model I power stand: 26.0''W x 26.0''D x 5.0''H (66 cm x 66 cm x 12.7 cm)
• L1 model I Cylindrical Radiator
®
loudspeaker (each section):
3.5''W x 4.0''D x 43.0''H (8.9 cm x 10.5 cm x 109.2 cm)
• R1 remote control: 2.8''W x 5.6''D x 1.6''H (7.1 cm x 14.1 cm x 4.0 cm)
• B1 bass module (optional):
10.3''W x 18.0''D x 15.3''H (25.0 cm x 45.7 cm x 38.0 cm)
Weight
• L1 model I power stand: 35 lb (16 kg)
• Lower L1 model I Cylindrical Radiator
®
loudspeaker: 16.0 lb (7 kg)
• Upper L1 model I Cylindrical Radiator
®
loudspeaker: 14.5 lb (6 kg)
• R1 remote control: 0.6 lb (0.27 kg)
• B1 bass module (optional): 28 lb (13 kg)
Electrical
Impedance
• L1 model I Cylindrical Radiator
®
loudspeaker: 4Ω
Lower L1 model I Cylindrical Radiator
®
loudspeaker: 8Ω
Upper L1 model I Cylindrical Radiator
®
loudspeaker: 8Ω
• B1 bass module (optional): 8Ω
AC power rating
• USA/Canada: 100-127V 50/60Hz 1000W
• International: 220-240V 50/60Hz 1000W
• USA/Canada peak inrush current: 32A @ 120V 60Hz
• International peak inrush current: 16A @ 230V 60Hz
Audio Input/Output
• Amplifier 1 output power: 250W (rms, into 4Ω), assigned to
L1 model I Cylindrical Radiator
®
loudspeaker
• Amplifier 2 output power: 250W (rms, into 4Ω), assigned to one or two B1 bass
modules using the B1 Bass Module connector
• Output level, Line OUT: Balanced XLR connection, +4dBu
• Output level, Bass–Line OUT:
•With a balanced TRS connection: -4dBu (nominal), +9dBu (max)
• With an unbalanced TS connection: -10dBu (nominal), +3dBu (max)
• Bass–Line OUT Frequency Response:
• With 1 or 2 B1 bass modules connected to B1 Bass Module: 40 -180Hz,
compensated for B1 bass module
• Without B1 bass modules connected to B1 Bass Module: 40 -180Hz, flat bandpass
• Data Output: 48KHz, S/PDIF compatible interface. L=Channel 1 output, R=Channel 2
output.
