CONTROLS AND INDICATORS
Control Console
Power light
• Red.....................System is off (Standby)
• Blinking green ....System is starting
• Steady green ......System is on and ready to use in the main room or other rooms
• Amber.................System off and charging iPod or iPhone
Front A/V inputs
Used for temporarily connecting an audio/video device such as a camcorder.
Headphones output
Accepts stereo headphones with a 3.5 mm stereo plug. Volume level is set by the
volume controls.
Control buttons
Front USB input
Used for viewing photo files from a USB device including a digital camera. Also used
for updating system software.
Front HDMI
TM
input
Used for temporarily connecting an HDMI device such as a video camera.
