Single Module Performance
Frequency Response (–3 dB)
(1)
75 Hz - 17 kHz
Frequency Range (–10 dB)
(1)
58 HZ - 18 kHz
Horizontal Dispersion
(2)
160°
Vertical Opening Angles Software Adjustable: 1 module: up to 30°; 2-3 modules: up to 40° Vertical
Vertical Beam Steering Angles ± 20°
seludoM-3seludoM-2eludoM-1ecnamrofreP eludoM elpitluM
Typical Usable Throw Distance
(4)
)tf 511( m 53)tf 28( m 52)tf 33( m 01
Distance )tf 89( m 03)tf 66( m 02)tf 33( m 01
Maximum SPL
(3)
at Distance )kaeP Bd 101( Bd 59)kaeP Bd 201( Bd 69)kaeP Bd 301( bd 79
Low-frequency Beam Control Limit zH 061zH 052zH 005
Driver Compliment, Full-r
ange Cones )ni 52.2( mm 75 x 63)ni 52.2( mm 75 x 42)ni 52.2( mm 75 x 21
Amplifier Channels / Rat
ed Power W 05 x 63W 05 x 42W 05 x 21
Physical Array Height )ni 711( m 3)ni 87( m 2)ni 93( m 1
Electrical Performance (Single Module)
A
C Mains Voltage Universal 85/264 VAC/50/60 Hz
AC Mains Connector IEC60320-C14
AC Power Consumption 120 VAC / 240 VAC: 25 W (idle), 275 W (max)
Audio Inputs
Analog Audio Input Connector 3-pin Phoenix connector
(5)
Analog Audio Maximum Input Level 0 dBu / +10 dBu / +24 dBu (pad engaged)
Input Sensitivity 15 dBu
Input Impedance 20k Ω
Digital Audio Inputs Input: 2 channels of Dante® digital audio network (RJ-45); Expansion: LVDS (RJ-50)
Digital Output Expansion: LVDS (RJ-50)
Integrated DSP
DSP Pla
tform / Network Support Bose ControlSpace®
A/D and D/A Converters 24-bit, 48 kHz
Number of Beams Supported
(5)
2
FIR Filter Support (Local MSA12X) 1024 tap @ 48 kHz
Number User Presets (Local MSA12X) 10
Audio Latency 5.7 ms
Physical
Enclosure Extruded aluminum sidewalls; steel end caps, all powder coated
Grille Powder-coated aluminum
Indicators and Controls Power, limit, fault
Operating Temperature Range (Ambient) 0 °C to 40 °C / 32 °F to 104 °F
Cooling System Cooling is passive only, airflow bottom to top
Environmental Indoor only
Suspension / Mounting Integrated wall brackets; allows horizontal yaw up to 90° in either direction
Dimensions (H x W x D) 984 x 106 x 206 mm (38.74 x 4.16 x 8.12 in)
Net Weight 14.5 kg (32 lbs)
Shipping Weight 19.2 kg (42.3 lbs)
Included Accessories (1) Power cord, (1) Power interconnect cable, (1) RJ-50 expansion cable, (1) Phoenix connector, (2) Wall/Spea
ker-mount bracket sets,
(1) Interconnect bracket, (12) Zip ties, (1) Bose logo, (4) M6 flange nuts, (8) M6 hex head bolts, (1) yaw bracket
Product Codes
Black (RAL 9005) UA ,KU ,PJ ,UE ,SU0115,0114,0113,0112,0111 - ]658787[
White (RAL 9010) UA ,KU ,PJ ,UE ,SU0125,0124,0123,0122,0121 - ]658787[
F
ootnotes
(1) Frequency response and range measured at 1 m, on-axis with recommended active EQ in anechoic environment
(2) 1-4k average, –6 dB
(3) Max SPL calculated based on free-field (no boundary loading gain) sensitivity, exclusive of power compression, and without beam steering, spreading or smoothing functions applied
(4) Typical Maximum Usable Throw Distance includes considerations for reverberation and speech intelligibility
(5) Analog audio input is limited to one (1) beam; two (2) beam support requires Dante input
