Bose Panaray MSA12X Service Manual

7
PACKAGING PART LIST
Panaray
®
MSA12X (see Figure 1)
Item
Number
Description Bose
®
Part
Number
Vendor Part Number Qty. Note
1, 2, 3 KIT, HARDWARE, CABLE SECURE
CONSISTS OF:
799698-001S - 1
CABLE TIE, NYLON, L = 4 INCH - 13-100320-000-U000 12
POLYBAG, 3.5”, ZIP, P - 94-000020-000-U003 2
STS, STL, D2.8XL10, PAN, BLK ZN-P - 10-101102-000-U000 12
4 LVDS EXTERNAL EXPANSION CABLE 792042-001S 46-503508-000-U000 1
5
ASSY, CABLE, LINE CORD, C13, JP/TWN
AC EXPANSION
803283-001S
46-100407-001-U000
13
6 ASSY, CABLE, AC EXPANSION, UL/CSA/
VDE/CCC/SAA
792043-001S
46-100407-002-U000
13
7 ASSY, CABLE, LINE CORD, C13, UK/KOR
AC EXPANSION
803284-001S
46-100407-003-U000
13
8, 9, 10
KIT, HARDWARE, MTG BRACKET
CONSISTS OF:
796738-001S - 1
FLAT WASHER, STL, 12X6.4X1.0, ZN-P - 11-000528-001-U000 (BLK)
11-000528-000-U000 (WHT)
4
HEX FLANGE NUT, STL, M6, 1.0P, ZN-P - 12-200376-001-U001 (BLK)
12-200376-000-U001 (WHT)
4
MS, STL, M6X16, HEX, 1.0P, ZN-P, 10.9 - 10-001795-001-U001 (BLK)
10-001795-000-U001 (WHT)
8
11 BRACKET, SPEAKER, BLK, SVCE 782393-011S 31-010508-020-U000 23
BRACKET
, SPEAKER, WHT, SVCE 782393-021S
31-010508-010-U000
12 POLYBAG, SPKR BKT, 300X120X0.05, PE - 94-000917-000-U000 2
13 BRACKET, WALL, BLK, SVCE 782395-011S 31-010509-020-U000 23
BRACKET
, WALL, WHT, SVCE 782395-021S
31-010509-010-U000
14 POLYBAG, WALL BKT, 170X120X0.05, PE - 94-000916-000-U000 3
15 POLYBAG, 1300*310*0.1, PE 799637-001S 94-000905-000-U000 1
16 CARTON, MSA12X 799631-001S 98-002718-010-U000 1
17 GUIDE, INSTALL, MSA12X 796790-0010 - 1
18 POLY BAG - 94-000039-000-U003 1
19 BRACKET, ANGLE ADJ, BLK, SVCE 800625-011S 31-011118-020-U000 1 3
BRACKET, ANGLE ADJ, WHT, SVCE 800625-021S 31-011118-010-U000
20 PE FOAM, BOTTOM 799636-001S 93-201832-000-U000 2
21
LOGO WITH POLYBAG, AL6063, BLK
LOGO WITH POLYBAG, AL6063, WHT
794420-011S
794420-021S
13-401638-003-U000
13-401638-002-U000
1
22 BRACKET, INTERCONNECT, BLK, SVCE 778709-011S 31-010507-020-U000 1 3
BRACKET, INTERCONNECT, WHT, SVCE 778709-021S 31-010507-010-U000
23 POLYBAG, INTER BKT, 340X70X0.05, PE - 94-000918-000-U000 1
