Bose Panaray MSA12X Service Manual

9
MAIN PART LIST
Panaray
®
MSA12X (see Figure 2)
Item
Number
Description Bose
®
Part
Number
Vendor Part Number Qty. Note
1 BREAKER, 240VAC, 10A, 48VDC, 50/60HZ,
SVCE
792619-001S 44-200332-000-U000 1 3
2 IEC EGRESS CONN, 158A, 250V, NIC-P SVCE
AC EXPANSION
787148-001S 40-004562-000-U000 1 3
3 HEATSINK PAD, OP8500, 22X26X1.0T 804943-001S 19-000943-003-U000 1 3
4 HEATSINK PAD, OP8500, 15X19X1.0T 804944-001S 19-000943-002-U000 8 3
5 ASSY, PCB, MCU/DSP 777168-001S 50-011128-002-R000 11
6
ASSY, PCB, AMP, 4 CHANNEL 777167-001S 50-011128-000-R000 11
7 ASSY, PCB, P/S 777169-001S 50-011128-003-R000 11
8 STANDOFF, HEX 6, STL, M3X44 796624-001S 12-000251-001--U000 2
9
ASSY, PCB, INTERCONNECT 792679-001S 50-011128-004-R000 1
10 DRIVER, 2.25 INCH, 5 OHM 318828-000S - 12
11 KIT, GRILLE/LOGO, BLK, SVCE 794422-011S - 1
1
1 KIT, GRILLE/LOGO, WHT, SVCE 794422-021S - 1
12
LOGO, MSA12X, BLK 794420-011S 13-401638-003-U000 1
12 LOGO, MSA12X, WHT 794420-021S 13-401638-002-U000 1
- ASSY, CABLE, LOW VOLTAGE POWER
(LV DC CABLE, #22, 55LX10WAY)
796617-001S 46-201586-000-U000 1
- ASSY, CABLE, FFC, MCU TO AMP
(MOLEX FFC CABLE, SD-15020-001)
796616-001S 46-201605-000-U000 1
- ASSY, CABLE, HIGH VOLTAGE POWER
(HV DC CABLE, #18, 55LX6WAY)
796618-001S 46-201587-000-U000 1 3
- AC POWER CABLE-PWR SUPPLY, #18,70LX-
2WAY
- 46-503531-000-U000 1 3
- AC PWR CORD, W/INLET MODULE, 630LX2WAY - 46-100403-001-U000 1 3
- AC POWER CABLE-BROWN, #14, 130L, UL1015,
R.1
- 46-503533-001-U000 1 3
- EARTH GROUND CABLE, #14, 70L, UL1015 - 46-503534-000-U000 1 3
- CONNECTOR, AC INLET, SHIELDED, PNL MNT 785003-001S 46-100403-002-U000 13
