Bose T1 ToneMatch - Page 21

13
SYSTEM SETUP
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
Figure 11
L1
TM
model I
connections to
a T1
Note: To avoid problems caused by ground loops, connect the power stand and the T1 power supply to the same AC
mains circuit.
¼" audio cable
(not supplied)
T1 ToneMatch
TM
power supply
(optional)
Channel 3 & 4 input
and Level control
