Bose ToneMatch T8S Service Manual

14
Resistors (continued)
ELECTRICAL PART LIST
T4S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
R44, R45, R46, R47, R230, R231, R232 CHIP, 33 OHM, 100PPM, +-1%, 0603,
WALSIN
T502330A02399
R50, R52, R238, R239, R336, R376, R412,
R452, R540, R546, R553, R556, R565, R570,
R578, R580
CHIP, 22 OHM, 100PPM, +-1%, 0603,
WALSIN
T502220A02399
R86, R295, R348, R374, R388, R411, R426,
R451, R468, R532, R543, R561, R579, R20,
R26, R113
CHIP, 1K OHM, 100PPM, +-1%, 0603,
WALSIN, WR06X1001FTL
T502100102399
R87, R88, R89, R90, R213, R589, R590,
R603, R604, R609, R610, R623, R624, R629,
R630, R643, R644, R649, R650, R663, R664
CHIP, 47 OHM, 100PPM, +-1%, 0603,
WALSIN
T502470A02399
R91, R92, R93, R94, R566, R573, R601,
R602, R611, R612, R641, R642, R651, R652,
R22
CHIP, 47K OHM, 100PPM, +-1%,
0603, WALSIN
T502470202399
R100, R101, R102 CHIP, 105K OHM, 100PPM, +-1%,
0603, WALSIN, WR06X1053FTL
T502105302399
R109, R110, R111, R112 CHIP, 24 OHM, 100PPM, +-1%, 0603,
WALSIN
T502240A02399
R114, R115 CHIP, 0 OHM, 0603, WALSIN,
WR06X000PTL
T502000002009
R122, R123, R124, R125 CHIP, 309 OHM, 100PPM, +-1%,
0603, WALSIN, WR06X309FTL
T502309002399
R139, R293, R307, R324, R338, R355, R369,
R387, R401
CHIP, 10 OHM, 200PPM, +-1%, 0603,
WALSIN, WR06X10R0FTL
T502100A02399
R211, R284, R286, R288, R294, R315, R319,
R343, R345, R346, R350, R356, R367, R378,
R380, R382, R384, R395, R407, R419, R423,
R436, R444, R458, R462, R533, R549, R557,
R558, R559, R575, R584, R585
CHIP, 1M OHM, 100PPM, +-1%, 0603,
WALSIN
T502100402399
R221 CHIP, 68 0HM, 100PPM, +-1%, 0402,
WALSIN
T502680A01399
R267, R299, R330, R361, R393 CHIP, 220 OHM, 100PPM, +-1%,
0603, WALSIN WR06X2200FTL
T502220002399
R268 CHIP, 113 OHM, 100PPM+-1%, 0603,
WALSIN, WR06X1130FTL
T502113002399
R273 CHIP, 340 OHM, 100PPM+-1%, 0603,
WALS, WR06X3400FTL
T502340002399
R274 CHIP, 95.3 OHM, 100PPM, +-1%,
0603, WALSIN, WR06X95R3FTL
T502953A02399
R285, R289, R316, R320, R347, R351, R379,
R383
CHIP, 10M OHM, 100PPM, +-1%,
0603, WALSIN
T502100502399
R292, R308, R323, R339, R354, R370, R386,
R402, R534, R552, R567, R583
CHIP, 91 OHM, 100PPM+-1%, 0603,
WALSIN
T502910A02399
R296, R303, R327, R333, R334, R358, R365,
R373, R390, R397, R408, R447
CHIP, 6.8K OHM, 100PPM, +-1%,
0603, WALSIN, WR06X6801FTL
T502680102399
R298 CHIP, 60.4K, 100PPM, +-1%, 0603,
WALSIN, WR06X6042FTL
T502604202399
