Bose ToneMatch T8S Service Manual

15
Resistors (continued)
ELECTRICAL PART LIST
T4S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
R309, R310, R340, R341, R371, R372, R403,
R404, R164, R165, R166, R167, R180, R181,
R182, R183, R197, R198, R199, R200
CHIP, 2K, OHM, 100PPM, +-1%,
0603, WALSIN
T502200102399
R317 CHIP, 22.1K OHM, 100PPM, +-1%,
0603, WALSIN
T502221202399
R318, R329, R349, R363, R389, R405, R427,
R440
CHIP, 3.3K OHM, 100PPM, +-1%,
0603, WALSIN
T502330102399
R321, R342, R352, R377, R392, R415, R430,
R455, R538, R544, R563, R568
CHIP, 3K OHM, 100PPM, +-1%, 0603,
WALSIN
T502300102399
R325, R357, R396, R437 CHIP, 820 OHM, 100PPM, +-1%,
0603, WALSIN
T502820002399
R326, R344, R360, R381, R399, R420, R439,
R459, R539, R545, R564, R569
CHIP, 330 OHM, 100PPM, +-1%,
0603, WALSIN, WR06X3300FTL
T502330002399
R332, R364, R406, R443, R541, R550, R576,
R581, R744, R745, R746, R747
CHIP, 56K OHM, 100PPM, +-1%,
0603, WALSIN
T502560202399
R375, R555 CHIP, 1K OHM, 100PPM, +-1%, 0402,
WALSIN
T502100101399
R536, R548, R560, R574, R591, R593, R597,
R599, R613, R615, R619, R621, R631, R633,
R637, R639, R653, R655, R659, R661, R667,
R668, R669, R670, R671, R672, R673, R674
CHIP, 6.2K OHM, 100PPM, +-1%,
0603, WALSIN
T502620102399
R587, R588, R605, R606, R607, R608, R625,
R626
CHIP, 7.5K OHM, 100PPM, +-1%,
0603, WALSIN
T502750102399
R627, R628, R645, R646, R647, R648, R665,
R666
CHIP, 15K OHM, 100PPM, +-1%,
0603, WALSIN
T502150202399
R632, R634, R638, R640, R654, R656, R660,
R662, R592, R594, R598, R600, R614, R616,
R620, R622
CHIP, 180 OHM, 100PPM, +-1%,
0603, WALSIN
T502180002399
RN1, RN2, RN3, RN4, RN5, RN6, RN7, RN8 RES NET, B, 68 OHM, 0402, 8P4R,
5%, WA04X680, JTL
T521068000108
Capacitors
Reference Designator Description Vendor Part
Number
Note
C1, C2, C3, C7, C8, C9 EL, 470UF, 25V, +-20%, 10*10,
CE1E471MDJANG
T551471445000
C4, C5, C6, C12, C21, C22, C23, C24, C26,
C27, C28, C45, C46, C49, C50, C61, C64,
C65, C66, C67, C68, C69, C70, C71, C72,
C73, C74, C75, C76, C77, C78, C79, C80,
C83, C84, C113, C115, C118, C119, C120,
C125, C126, C127, C128, C129, C130, C131,
C132, C133, C134, C135, C136, C137, C138,
C139, C140, C141, C142, C143, C144, C145,
C146, C147, C148, C149, C150, C151, C152,
C153, C154, C155, C156, C160, C161, C162,
C163, C164, C165, C166, C167, C168, C169,
C170, C171, C172, C175, C177, C178, C180,
C181, C183, C184, C185, C187, C188, C189,
C190, C192, C193, C197, C205, C207, C234
CAP, X7R, .10UF, 25V, +-10%, 0402,
WALSIN
T542011047408
