Bose ToneMatch T8S Service Manual

16
ELECTRICAL PART LIST
Capacitors (continued)
T4S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
C235, C238, C239, C262, C263, C266, C267,
C290, C291, C294, C295, C319, C320, C323,
C324, C455, C456, C461, C462, C544, C545,
C546, C547, C550, C551, C552, C553, C62,
C63, C42, C43, C44, C47, C114, C116, C117,
C121, C199
CAP, X7R, .10UF, 25V, +-10%, 0402,
WALSIN
T542011047408
C10, C15, C86, C87, C88, C90, C91, C92,
C93, C94, C95, C97, C98, C99, C100, C101,
C102, C103, C104, C105, C111, C112
CAP, X7R, .01UF, 50V+-10%, 0603,
WALSIN
T542021037508
C13, C248, C275, C304, C332, C478, C479,
C486, C487, C488, C489, C496, C497
CAP, NPO, 220PF, 50V+-5%, 0603,
WALSIN
T541022216508
C14, C443, C450, C458, C470 CAP, NPO, 330PF, 50V+-5%, 0603,
WALSIN
T541023316508
C17 EL, 100UF, 63V, +-20%, 10X10,
VZH101M1JTR-1010
T551101475020
C18 CAP, X7R, .01UF, 100V, +-10%, 0805,
WALSIN
T542031037608
C19 CAP, X7R, .10UF, 100V, +-10%, 0603,
WALSIN
T542021047608
C20 CAP, X7R, .47UF, 16V, +-10%, 0603,
WALSIN
T542024747308
C25, C33, C54 CAP, X7R, 10UF, 25V, +-10%, 1206,
WALSIN
T542041067408
C29, C209, C217, C229, C245, C257, C273,
C285, C302, C314, C498, C499, C506, C507,
C508, C509, C516, C517
CAP, NPO, 100PF, 50V, +-5%, 0603,
WALSIN
T541021016508
C30 CAP, NPO, 82PF, 50V, +-5%, 0603,
WALSIN, L0603N820J500CT
T541028206508
C31, C32, C34, C35, C36, C37, C38, C57,
C58
CAP, X5R, 22UF, 16V, +-20%, 0805,
WALSIN
T545032268308
C39 EL, 470UF, 16V, +-20%, 8*10.5, CK-
1C471M-CRF10
T551471434010
C48, C51, C52, C59, C60, C206, C11 EL, 100UF, 25V, +-20%, 6.3*7, DV-
101M025E077ETR
T551101445010
C56 CAP, NPO, 56PF, 50V, +-5%, 0603,
WALSIN
T541025606508
C40 CAP, NPO, 22PF, 50V, +-5%, 0402,
WALSIN, 0402N220J500CT
T541012206508
C81, C82, C157, C158 CAP, NPO, 18PF, 50V, +-5%, 0603,
WALSIN
T541021806508
C85, C89 CAP, X7R, 2.2UF, 6.3V, +-10%, 0603,
WALSIN
T542022257108
C96 CAP, X7R, .33UF, 25V+-10%, 0603,
WALSIN
T542023347408
C106 CAP, NPO, 12PF, 50V, +-5%, 0402,
WALSIN
T541011206508
C107, C108, C109 CAP, NPO, 22PF, 50V, +-5%, 0603,
WALSIN
T541022206508
