Bose ToneMatch T8S Service Manual

17
ELECTRICAL PART LIST
Capacitors (continued)
T4S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
C110 CAP, X7R, 1000P, 1KV, +-10%, 1206,
WALSIN
T542041027H08
C122, C123, C124, C159, C174, C176, C179,
C182, C186, C191, C198, C201, C219, C541,
C41
CAP, 10UF, 6.3V, +, -20%, 0603X5R,
WALSIN
T540000002118
C194 EL, 220UF, 6.3V, +-20%, 6.3*5, CK-
0J221M-CRE54
T551221414000
C195, C196 CAP, X7R, 1.0UF, 16V, +-10%, 0603,
WALSIN
T542021057308
C208 CAP, X7R, 4.7UF, 6.3V, +-10%, 0603,
WALSIN
T542024757108
C210 CAP, X7R, .047U, 50V, +-10%, 0603,
WALSIN, 0603B473K500CT
T542024737508
C215, C221, C223, C237, C243, C249, C251,
C265, C271, C277, C279, C293, C300, C306,
C308, C322, C441, C449, C453, C459, C460,
C473, C474, C477
CAP, NPO, .10UF, 50V, +-5%, 1206,
MURATA
T541041046505
C216, C218, C222, C233, C244, C246, C250,
C261, C272, C274, C278, C289, C301, C303,
C307, C318
EL, 22UF, 63V, +-20%, 6.3X7,
VZH220M1JTR-0607
T551220475010
C225, C241, C253, C269, C281, C297, C310,
C326
CAP, X7R, .10UF, 25V, +-10%, 0603,
WALSIN
T542021047408
C226, C242, C254, C270, C282, C298, C311,
C327, C542, C543
CAP, X7R, 1.0UF, 25V, +-10%, 0603,
WALSIN
T542021057408
C227, C276, C305, C333, C444, C446, C447,
C464, C466, C469
CAP, NPO, 2700PF, 50V, +-5%, 0603,
WALSIN
T541022726508
C228, C256, C284, C313, C445, C451, C465,
C468, C471, C475, C484, C485, C490, C491,
C504, C505, C510, C511
CAP, NPO, 470PF, 50V, +-5%, 0603,
WALSIN
T541024716508
C230, C231, C258, C259, C286, C287, C315,
C316
CAP, X7R, 2.2UF, 100V, +-10%, 1206,
SAMSUNG
T54204225760E
C232, C252, C255, C280, C283, C309, C312,
C337
CAP, NPO, 270PF, 50V, +-5%, 0603,
WALSIN, 0603N271J500CT
T541022716508
C236, C240, C264, C268, C292, C296, C321,
C325, C457, C463, C548, C549
CAP, X5R, 10UF, 25V, +-10%, 0805,
WALSIN, 0805X106K250CT
T545031067408
C247, C260, C288, C317 EL, 1000U, 10V, +-20%, 10X10,
HV102M010G105ETR
T551102425010
C299, C454 CAP, X5R, 4.7UF, 6.3V, +-10%, 0402,
WALSIN
T545014757108
C442, C452, C467, C476, C480, C481, C492,
C493, C500, C501, C512, C513
EL, 22UF, 16V, +-20%, 4X5.4M, CK-
1C220M-CRC54
T551220434010
C448, C472 CAP, NPO, 47PF, 50V, +-5%, 0603,
WALSIN
T541024706508
C502, C503, C514, C515, C482, C483, C494,
C495
CAP, NPO, 1200P, 50V, +-5%, 0603,
WALSIN, 0603N122J500CT
T541021226508
