18
ELECTRICAL PART LIST
Inductors
T4S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
L1, L2, L4, L5 CHIP, BEAD, 120 OHM, 5A, 25%,
0805, 100MHZ, FBMA-11-201209-
121A50T
T710500001600
L3 220UH, 370MA, 5.6M, SMD, COIL
CR, LPS6235-224MRB
T621000033800
L6 15UH, 3A, 100K, SMD, SGTE,
GPSR0640-150M
T621000003700
L7 3.3UH, 2.5A, 100K, SMD, GANTON,
GPSR0420-3R3M
T621000023900
L9, L8 IND, 10UH, 2.6A, 100K, SMD, TSA,
SDS0635, SDS0635M-100NT
T621000037200
L10, L11, L12, L13 BEAD, FBMA-11-160808-601A10T,
600 OHM, 10
T710500000900
L17 4.7UH, 1.8A, 100K, SMD, COILCR,
LPS4018-472MRC
T621000039500
Diodes
Reference Designator Description Vendor Part
Number
Note
D1 SWITCH, 100V, 1A, S100W, PAN T572005252110
D2, D3, D4, D5, D6, D7, D10, D11, D12, D13,
D14, D15, D18, D19, D20, D21, D22, D23,
D26, D27, D28, D29, D30, D31, D68, D72
SWITCH, 75V, 150MA, BAV99W, PAN T572005801210
D8, D9, D16, D17, D24, D25, D32, D33 LED, RED, 0805, INH-
S2012CHR20TP-B, MINGSHOU
T575009480258
D34, D35 DIODE, 40V, 1A, SS14L, TSC T571000130604
D66, D67, D71, D73, D74, D75, D76, D77,
D78, D79, D80, D81
DIODE, VR, AVRM1005C120MTAAB,
TDK
T710500020400
D86 SWITCH, 40V, 250MA,
NSR0240HT1G, ON SEMI
T572005830222
LED1, LED2, LED3, LED4 LED, 615, 1.6X1, EVERLIGHT, K19-
226\R6GHC-D05\2T
T575011450202
LED5, LED6, LED7, LED9, LED36, LED37,
LED38, LED39, LED40, LED41, LED42,
LED43, LED44, LED45, LED50, LED52,
LED53, LED54, LED55, LED60, LED61,
LED62, LED63, LED68, LED69, LED70,
LED71
LED, WHI, 0603, 19-217-T1D-A, EV-
ERLIGHT, 19-217-T1D-AQRHY-3T
T575006150202
LED77 LED, RED, 5.4X3, KH-3R4SD-40,
MINGSHOU
T575011140158
ZD1, ZD2, ZD3, ZD4, ZD5, ZD6, ZD7, ZD8 DIODE, ZENER, 5.6V, 250MW, 5%,
SOT-23, NXP
T573003610415
To Next Page
