23
ELECTRICAL PART LIST
T8S Main PCB Assembly
Resistors (continued)
Reference Designator Description Vendor Part
Number
Note
R26 CHIP, 13.7K OHM, 100PPM, +/-1%,
0603, WALSIN, WR06X1372FTL
T502137202399
R27 CHIP, 60.4K OHM, 100PPM, +/-1%,
0603, WALSIN, WR06X6042FTL
T502604202399
R28 CHIP, 22.1K OHM, 100PPM, +/-1%,
0603, WALSIN,
T502221202399
R35, R542, R551, R577, R582 CHIP, 12K OHM, 100PPM, +/-1%, 0603,
WALSIN
T502120202399
R37, R38, R39, R40, R41, R42, R43, R48,
R49, R51, R53, R54, R55, R56, R57, R58,
R59, R60, R140, R196, R216, R217, R222,
R226, R227, R228, R233, R234, R235,
R236, R237, R240, R241, R242, R243,
R244, R245, R246, R247, R248, R249,
R250, R251, R252, R253, R254, R255,
R256, R257, R258, R259, R260, R265,
R278, R279, R281
CHIP, 68.1 OHM, 100PPM, +/-1%, 0603,
WALSIN, WR06X68R1FTL
T502681A02399
R44, R45, R46, R47, R230, R231, R232 CHIP, 33 OHM, 100PPM, +/-1%, 0603,
WALSIN
T502330A02399
R50, R52, R238, R239, R336_A, R336_B,
R336_C, R336_D, R336_E, R336_F,
R336_G, R336_H, R540, R546, R553,
R556, R565, R570, R578, R580
CHIP, 22 OHM, 100PPM, +/-1%, 0603,
WALSIN
T502220A02399
R86, R295_A, R295_B, R295_C, R295_D,
R295_E, R295_F, R295_G, R295_H,
R348_A, R348_B, R348_C, R348_D,
R348_E, R348_F, R348_G, R348_H, R532,
R543, R561, R579, R17, R261, R298
CHIP, 1K OHM, 100PPM, +/-1%, 0603,
WALSIN, WR06X1001FTL
T502100102399
R87, R88, R89, R90, R213, R589, R590,
R603, R604, R609, R610, R623, R624,
R629, R630, R643, R644, R649, R650,
R663, R664, R669, R670, R683, R684,
R689, R691, R701, R704
CHIP, 47, OHM, 100PPM, +/-1%, 0603,
WALSIN
T502470A02399
R91, R92, R93, R94, R566, R573, R601,
R602, R611, R612, R641, R642, R651,
R652, R681, R682, R690, R692, R18
CHIP, 47K OHM, 100PPM, +/-1%, 0603,
WALSIN
T502470202399
R113, R114, R122, R123, R124, R125,
R126, R127, R128, R129
CHIP, 309 OHM, 100PPM, +/-1%, 0603,
WALSIN, WR06X309FTL
T502309002399
R139, R293_A, R293_B, R293_C, R293_D,
R293_E, R293_F, R293_G, R293_H,
R307_A, R307_B, R307_C, R307_D,
R307_E, R307_F, R307_G, R307_H
CHIP, 10 OHM, 200PPM, +/-1%, 0603,
WALSIN, WR06X10R0FTL
T502100A02399
R155, R301 CHIP, 0 OHM, 0603, WALSIN,
WR06X000PTL
T502000002009
R211, R284_A, R284_B, R284_C, R284_D,
R284_E, R284_F, R284_G, R284_H,
R286_A, R286_B, R286_C, R286_D,
R286_E, R286_F, R286_G, R286_H,
R288_A, R288_B, R288_C, R288_D,
R288_E, R288_F, R288_G, R288_H,
R294_A, R294_B, R294_C, R294_D
CHIP, 1M OHM, 100PPM, +/-1%, 0603,
WALSIN
T502100402399
To Next Page
