Bose ToneMatch T8S Service Manual

24
ELECTRICAL PART LIST
Reference Designator Description Vendor Part
Number
Note
R294_E, R294_F, R294_G, R294_H,
R343_A, R343_B, R343_C, R343_D,
R343_E, R343_F, R343_G, R343_H,
R345_A, R345_B, R345_C, R345_D,
R345_E, R345_F, R345_G, R345_H, R533,
R549, R557, R558, R559, R575, R584,
R585
CHIP, 1M OHM, 100PPM, +/-1%, 0603,
WALSIN
T502100402399
R221 CHIP, 68 0HM, 100PPM, +/-1%, 0402,
WALSIN
T502680A01399
R267, R299_A, R299_B, R299_C, R299_D,
R299_E, R299_F, R299_G, R299_H
CHIP, 220 OHM, 100PPM, +/-1%, 0603,
WALSIN, WR06X2200FTL
T502220002399
R268 CHIP, 113 OHM, 100PPM, +/-1%, 0603,
WALS, L, WR06X1130FTL
T502113002399
R275, R276, R277 CHIP, 105K OHM, 100PPM, +/-1%,
0603, WALSIN, WR06X1053FTL
T502105302399
R282, R283, R287, R290 CHIP, 24 OHM, 100PPM, +/-1%, 0603,
WALSIN
T502240A02399
R285_A, R285_B, R285_C, R285_D,
R285_E, R285_F, R285_G, R285_H,
R289_A, R289_B, R289_C, R289_D,
R289_E, R289_F, R289_G, R289_H
CHIP, 10M OHM, 100PPM, +/-1%, 0603,
WALSIN
T502100502399
R292_A, R292_B, R292_C, R292_D,
R292_E, R292_F, R292_G, R292_H,
R308_A, R308_B, R308_C, R308_D,
R308_E, R308_F, R308_G, R308_H, R534,
R552, R567, R583
CHIP, 91 OHM, 100PPM, +/-1%, 0603,
WALSIN
T502910A02399
R296_A, R296_B, R296_C, R296_D,
R296_E, R296_F, R296_G, R296_H,
R303_A, R303_B, R303_C, R303_D,
R303_E, R303_F, R303_G, R303_H,
R333_A, R333_B, R333_C, R333_D,
R333_E, R333_F, R333_G, R333_H
CHIP, 6.8K OHM, 100PPM, +/-1%,
0603, WALSIN, WR06X6801FTL
T502680102399
R309_A, R309_B, R309_C, R309_D,
R309_E, R309_F, R309_G, R309_H,
R310_A, R310_B, R310_C, R310_D,
R310_E, R310_F, R310_G, R310_H, R164,
R165, R166, R167, R168, R169, R170,
R171, R180, R181, R182, R183, R184,
R185, R186, R187, R197, R198, R199,
R200, R201, R202, R203, R204
CHIP, 2K OHM, 100PPM, +/-1%, 0603,
WALSIN
T502200102399
R318_A, R318_B, R318_C, R318_D,
R318_E, R318_F, R318_G, R318_H,
R329_A, R329_B, R329_C, R329_D,
R329_E, R329_F, R329_G, R329_H
CHIP, 3.3K OHM, 100PPM, +/-1%,
0603, WALSIN,
T502330102399
R321_A, R321_B, R321_C, R321_D,
R321_E, R321_F, R321_G, R321_H,
R342_A, R342_B, R342_C, R342_D,
R342_E, R342_F, R342_G, R342_H, R538,
R544, R563, R568
CHIP, 3K OHM, 100PPM, +/-1%, 0603,
WALSIN
T502300102399
R325_A, R325_B, R325_C, R325_D,
R325_E, R325_F, R325_G, R325_H
CHIP, 820 OHM, 100PPM, +/-1%, 0603,
WALSIN
T502820002399
T8S Main PCB Assembly
Resistors (continued)

Bose ToneMatch T8S Specifications

General

Channels	8
Type	Digital mixer
Inputs	8 XLR/TRS combo
Outputs	2 XLR
Effects	Yes
Phantom Power	Yes
EQ	3-band on each channel
USB	Yes
