25
ELECTRICAL PART LIST
T8S Main PCB Assembly
Resistors (continued)
Reference Designator Description Vendor Part
Number
Note
R326_A, R326_B, R326_C, R326_D,
R326_E, R326_F, R326_G, R326_H,
R344_A, R344_B, R344_C, R344_D,
R344_E, R344_F, R344_G, R344_H, R539,
R545, R564, R569
CHIP, 330 OHM, 100PPM, +/-1%, 0603,
WALSIN, WR06X3300FTL
T502330002399
R332_A, R332_B, R332_C, R332_D,
R332_E, R332_F, R332_G, R332_H, R541,
R550, R576, R581, R744_A, R744_B,
R744_C, R744_D, R744_E, R744_F,
R744_G, R744_H
CHIP, 56K OHM, 100PPM, +/-1%, 0603,
WALSIN
T502560202399
R375, R438, R555 CHIP, 1K OHM, 100PPM, +/-1%, 0402,
WALSIN
T502100101399
R536, R548, R560, R574, R591, R593,
R597, R599, R613, R615, R619, R621,
R631, R633, R637, R639, R653, R655,
R659, R661, R671, R674, R677, R679,
R693, R696, R699, R702
CHIP, 6.2K OHM, 100PPM, +/-1%,
0603, WALSIN
T502620102399
R587, R588, R605, R606, R607, R608,
R625, R626, R627, R628, R645, R646,
R647, R648, R665, R666, R667, R668,
R685, R686, R687, R688, R705, R706
CHIP, 15K OHM, 100PPM, +/-1%, 0603,
WALSIN
T502150202399
R592, R594, R598, R600, R614, R616,
R620, R622, R632, R634, R638, R640,
R654, R656, R660, R662, R672, R675,
R678, R680, R694, R697, R700, R703
CHIP, 180 OHM, 100PPM, +/-1%, 0603,
WALSIN
T502180002399
RN1, RN2, RN3, RN4, RN5, RN6, RN7,
RN8
RES NET, B, 68 OHM, 0402, 8P4R, 5%,
WA04X680, JTL
T521068000108
Capacitors
Reference Designator Description Vendor Part
Number
Note
C1, C2, C3, C7, C8, C9 EL, 470UF, 25V, +/-20%, 10*10,
CE1E471MDJANG
T551471445000
C4, C5, C6, C12, C24, C25, C26, C45,
C46, C49, C50, C61, C64, C65, C66, C67,
C68, C69, C70, C71, C72, C73, C74, C75,
C76, C77, C78, C79, C80, C83, C84, C110,
C113, C114, C115, C116, C117, C118,
C119, C120, C125, C126, C127, C128,
C129, C130, C131, C132, C133, C134,
C135, C136, C137, C138, C139, C140,
C141, C142, C143, C144, C145, C146,
C147, C148, C149, C150, C151, C152,
C153, C154, C155, C156, C160, C161,
C162, C163, C164, C165, C166, C167,
C168, C169, C170, C171, C172, C180,
C181, C183, C184, C185, C187, C188,
C189, C190, C192, C193, C197, C199,
C200, C202, C203, C204, C205, C207,
C214, C234_A, C234_B, C234_C, C234_D,
C234_E, C234_F, C234_G, C234_H,
C235_A, C235_B, C235_C, C235_D
CAP, X7R, .10UF, 25V, +/-10%, 0402,
WALSIN
T542011047408
To Next Page
