26
Capacitors (continued)
ELECTRICAL PART LIST
T8S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
C235_E, C235_F, C235_G, C235_H,
C238_A, C238_B, C238_C, C238_D,
C238_E, C238_F, C238_G, C238_H,
C239_A, C239_B, C239_C, C239_D,
C239_E, C239_F, C239_G, C239_H, C455,
C456, C461, C462, C544, C545, C546,
C547, C550, C551, C552, C553, C554,
C555, C556, C557, C178, C182, C186, C47,
C53, C55, C56, C177, C243, C244, C245,
C246, C249, C250, C251
CAP, X7R, .10UF, 25V, +/-10%, 0402,
WALSIN
T542011047408
C10, C15, C86, C87, C88, C90, C91, C92,
C93, C94, C95, C97, C98, C99, C100,
C101, C102, C103, C104, C105, C106,
C107, C108, C109, C111, C112
CAP, X7R, .01UF, 50V, +/-10%, 0603,
WALSIN
T542021037508
C13, C248_A, C248_B, C248_C, C248_D,
C248_E, C248_F, C248_G, C248_H
CAP, NPO, 220PF, 50V, +/-5%, 0603,
WALSIN
T541022216508
C14, C443, C450, C458, C470 CAP, NPO, 330PF, 50V, +/-5%, 0603,
WALSIN
T541023316508
C17 EL, 100UF, 63V, +/-20%, 10X10,
VZH101M1JTR-1010
T551101475020
C18 CAP, X7R, .01UF, 100V, +/-10%, 0805,
WALSIN
T542031037608
C19 CAP, X7R, .10UF, 100V, +/-10%, 0603,
WALSIN
T542021047608
C20 CAP, X7R, .47UF, 16V, +/-10%, 0603,
WALSIN
T542024747308
C21, C22, C23, C31 CAP, X7R, .10UF, 50V, +/-10%, 0402,
WALSIN
T542011047508
C27 EL, 470UF, 16V, +/-20%, 8*10.5, CK-
1C471M-CRF10
T551471434010
C28 CAP, NPO, 82PF, 50V, +/-5%, 0603,
WALSIN, 0603N820J500CT
T541028206508
C29, C30, C33, C34, C35, C36, C37, C600,
C40
CAP, X5R, 22UF, 16V, +/-20%, 0805,
WALSIN
T545032268308
C32, C209, C217_A, C217_B, C217_C,
C217_D, C217_E, C217_F, C217_G,
C217_H, C229_A, C229_B, C229_C,
C229_D, C229_E, C229_F, C229_G,
C229_H, C478, C479, C486, C487, C488,
C489, C496, C497, C498, C499, C506,
C507, C508, C509, C516, C517, C518,
C519, C526, C527, C528, C530, C536,
C537
CAP, NPO, 100PF, 50V, +/-5%, 0603,
WALSIN
T541021016508
C38 CAP, NPO, 56PF, 50V, +/-5%, 0603,
WALSIN
T541025606508
C39 CAP, NPO, 22PF, 50V, +/-5%, 0402,
WALSIN, 0402N220J500CT
T541012206508
C41, C42, C43, CAP, X7R, 10UF, 25V, +/-10%, 1206,
WALSIN
T542041067408
C48, C51, C52, C59, C60, C206, C11 EL, 100UF, 25V, +/-20%, 6.3*7, DV-
101M025E077ETR
T551101445010
To Next Page
