27
ELECTRICAL PART LIST
Capacitors (continued)
T8S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
C58 CAP, NPO, 12PF, 50V, +/-5%, 0402,
WALSIN
T541011206508
C62, C63, C121 CAP, NPO, 22PF, 50V, +/-5%, 0603,
WALSIN
T541022206508
C81, C82, C157, C158 CAP, NPO, 18PF, 50V, +/-5%, 0603,
WALSIN
T541021806508
C85, C89 CAP, X7R, 2.2UF, 6.3V, +/-10%, 0603,
WALSIN
T542022257108
C96 CAP, X7R, .33UF, 25V, +/-10%, 0603,
WALSIN
T542023347408
C122, C123, C124, C159, C174, C176,
C179, C191, C198, C201, C219, C220,
C224, C541, C44
CAP, 10UF, 6.3V, +/-20%, 0603X5R,
WALSIN
T540000002118
C175 CAP, X7R, 1000PF, 1KV, +/-10%, 1206,
WALSIN
T542041027H08
C194, C211 EL, 220UF, 6.3V, +/-20%, 6.3*5, CK-
0J221M-CRE54
T551221414000
C195, C196, C212, C213 CAP, X7R, 1.0UF, 16V, +/-10%, 0603,
WALSIN
T542021057308
C208 CAP, X7R, 4.7UF, 6.3V, +/-10%, 0603,
WALSIN
T542024757108
C210 CAP, X7R, .047U, 50V, +/-10%, 0603,
WALSIN, 0603B473K500CT
T542024737508
C215_A, C215_B, C215_C, C215_D,
C215_E, C215_F, C215_G, C215_H,
C221_A, C221_B, C221_C, C221_D,
C221_E, C221_F, C221_G, C221_H,
C223_A, C223_B, C223_C, C223_D,
C223_E, C223_F, C223_G, C223_H,
C237_A, C237_B, C237_C, C237_D,
C237_E, C237_F, C237_G, C237_H, C441,
C449, C453, C459, C460, C473, C474,
C477
CAP, NPO, .10UF, 50V, +/-5%, 1206,
MURATA
T541041046505
C216_A, C216_B, C216_C, C216_D,
C216_E, C216_F, C216_G, C216_H,
C218_A, C218_B, C218_C, C218_D,
C218_E, C218_F, C218_G, C218_H,
C222_A, C222_B, C222_C, C222_D,
C222_E, C222_F, C222_G, C222_H,
C233_A, C233_B, C233_C, C233_D,
C233_E, C233_F, C233_G, C233_H
EL, 22UF, 63V, +/-20%, 6.3X7,
VZH220M1JTR-0607
T551220475010
C225_A, C225_B, C225_C, C225_D,
C225_E, C225_F, C225_G, C225_H,
C241_A, C241_B, C241_C, C241_D,
C241_E, C241_F, C241_G, C241_H
CAP, X7R, .10UF, 25V, +/-10%, 0603,
WALSIN
T542021047408
C226_A, C226_B, C226_C, C226_D,
C226_E, C226_F, C226_G, C226_H,
C242_A, C242_B, C242_C, C242_D,
C242_E, C242_F, C242_G, C242_H, C542,
C543
CAP, X7R, 1.0UF, 25V, +/-10%, 0603,
WALSIN
T542021057408
To Next Page
