28
ELECTRICAL PART LIST
Capacitors (continued)
T8S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
C227_A, C227_B, C227_C, C227_D,
C227_E, C227_F, C227_G, C227_H, C444,
C446, C447, C464, C466, C469
CAP, NPO, 2700P, 50V, +/-5%, 0603,
WALSIN
T541022726508
C228_A, C228_B, C228_C, C228_D,
C228_E, C228_F, C228_G, C228_H, C445,
C451, C465, C468, C471, C475, C484,
C485, C490, C491, C504, C505, C510,
C511, C524, C525, C529, C531
CAP, NPO, 470PF, 50V, +/-5%, 0603,
WALSIN
T541024716508
C230_A, C230_B, C230_C, C230_D,
C230_E, C230_F, C230_G, C230_H,
C231_A, C231_B, C231_C, C231_D,
C231_E, C231_F, C231_G, C231_H
CAP, X7R, 2.2UF, 100V, +/-10%, 1206,
SAMSUNG
T54204225760E
C232_A, C232_B, C232_C, C232_D,
C232_E, C232_F, C232_G, C232_H,
C252_A, C252_B, C252_C, C252_D,
C252_E, C252_F, C252_G, C252_H
CAP, NPO, 270PF, 50V, +/-5%, 0603,
WALSIN, 0603N271J500CT
T541022716508
C236_A, C236_B, C236_C, C236_D,
C236_E, C236_F, C236_G, C236_H,
C240_A, C240_B, C240_C, C240_D,
C240_E, C240_F, C240_G, C240_H, C457,
C463, C548, C549, C558, C559
CAP, X5R, 10UF, 25V, +/-10%, 0805,
WALSIN, 0805X106K250CT
T545031067408
C247_A, C247_B, C247_C, C247_D,
C247_E, C247_F, C247_G, C247_H
EL, 1000UF, 10V, +/-20%, 10X10,
HV102M010G105ETR
T551102425010
C299, C356, C454 CAP, X5R, 4.7UF, 6.3V, +/-10%, 0402,
WALSIN
T545014757108
C442, C452, C467, C476, C480, C481,
C492, C493, C500, C501, C512, C513,
C520, C521, C532, C533
EL, 22UF, 16V, +/-20%, 4X5.4M, CK-
1C220M-CRC54
T551220434010
C448, C472 CAP, NPO, 47PF, 50V, +/-5%, 0603,
WALSIN
T541024706508
C482, C483, C494, C495, C502, C503,
C514, C515, C522, C523, C534, C535
CAP, NPO, 1200P, 50V, +/-5%, 0603,
WALSIN, 0603N122J500CT
T541021226508
Inductors
Reference Designator Description Vendor Part
Number
Note
L1, L2, L4, L5 CHIP, BEAD, 120 OHM, 5A, 25%, 0805,
100MHZ, FBMA-11-201209-121A50T
T710500001600
L3 220UH, 370MA, 5.6M, SMD, COILCR,
LPS6235-224MRB
T621000033800
L6 15UH, 3A, 100K, SMD, SGTE,
GPSR0640-150M
T621000003700
L7 3.3UH, 2.5A, 100K, SMD, GANTON,
GPSR0420-3R3M
T621000023900
L9, L8 10UH, 2.6A, 100K, SMD, TSA,
SDS0635M-100NT
T621000037200
L10, L11, L12, L13 BEAD, FBMA-11-160808-601A10T, 600
OHM, 10
T710500000900
L17 4.7UH, 1.8A, 100K, SMD, COILCR,
LPS4018, LPS4018-472MRC
T621000039500
To Next Page
