29
ELECTRICAL PART LIST
Diodes
T8S Main PCB Assembly
Transistors
Reference Designator Description Vendor Part
Number
Note
Q1 NMOS, 60V, AO6420, TSOP, AOS T586003042546
Q2_A, Q2_B, Q2_C, Q2_D, Q2_E, Q2_F,
Q2_G, Q2_H, Q3_A, Q3_B, Q3_C, Q3_D,
Q3_E, Q3_F, Q3_G, Q3_H, Q4_A, Q4_B,
Q4_C, Q4_D, Q4_E, Q4_F, Q4_G, Q4_H
PNP, -40V, MMBT4403, SOT23, FAIR-
CHILD
T582002690404
Reference Designator Description Vendor Part
Number
Note
D1 SWITCH, 100V, 1A, S100W, PAN T572005252110
D2_A, D2_B, D2_C, D2_D, D2_E, D2_F,
D2_G, D2_H, D3_A, D3_B, D3_C, D3_D,
D3_E, D3_F, D3_G, D3_H, D4_A, D4_B,
D4_C, D4_D, D4_E, D4_F, D4_G, D4_H,
D5_A, D5_B, D5_C, D5_D, D5_E, D5_F,
D5_G, D5_H, D6_A, D6_B, D6_C, D6_D,
D6_E, D6_F, D6_G, D6_H, D7_A, D7_B,
D7_C, D7_D, D7_E, D7_F, D7_G, D7_H,
D68, D72
SWITCH, 70V, 215MA, BAV99LT1G,
ON-SEMI
T572003550122
D8_A, D8_B, D8_C, D8_D, D8_E, D8_F,
D8_G, D8_H, D9_A, D9_B, D9_C, D9_D,
D9_E, D9_F, D9_G, D9_H
LED, RED, 0805, INH-
S2012CHR20TP-B, MINGSHOU
T575009480258
D10, D11 DIODE, 40V, 1A, SS14L, TSC T571000130604
D12, D13, D14, D15, D16, D17, D18, D19,
D20, D21, D22
TVS, 5.78, RSB6.8SM, SMD, ROHM T593000194100
D66, D67, D71, D73, D74, D75, D76, D77,
D78, D79, D80, D81, D82, D83, D84, D85
VR, AVRM1005C120MTAAB, TDK T710500020400
D86 SWITCH, 40V, 250MA, NSR0240HT1G,
ON-SEMI
T572005830222
LED1, LED2, LED3, LED4, LED5, LED6,
LED7, LED8
LED, 615, 1.6X1, 19-226\R6GHC-
D05\2T, EVERLIGHT
T575011450202
LED10, LED11, LED12, LED9, LED18,
LED19, LED20, LED21, LED22, LED23,
LED24, LED25, LED26, LED28, LED29,
LED30, LED31, LED32, LED33, LED34,
LED35, LED36, LED37, LED38, LED39,
LED40, LED41, LED42, LED43, LED44,
LED45, LED46, LED47, LED48, LED49,
LED50, LED52, LED53, LED54, LED55,
LED56, LED57, LED58, LED59, LED60,
LED61, LED62, LED63, LED64, LED65,
LED66, LED67, LED68, LED69, LED70,
LED71, LED72, LED73, LED74, LED75
LED, WHITE, 0603, 19-217-T1D-AQ-
RHY-3T, EVERLIGHT
T575006150202
LED17, LED27 LED, RED, 19-213\R6SC-AR2S2B\3T,
EVERLIGHT
T575011460202
LED77 LED, RED, 5.4X3., KH-3R4SD-40,
MINGSHOU
T575011140158
ZD1_A, ZD2_A, ZD1_B, ZD2_B, ZD1_C,
ZD2_C, ZD1_D, ZD2_D, ZD1_E, ZD2_E,
ZD1_F, ZD2_F, ZD1_G, ZD2_G, ZD1_H,
ZD2_H
ZD, 5.6V, 250MW, 5%, SOT-23, NXP T573003610415
To Next Page
