30
ELECTRICAL PART LIST
Integrated Circuits
Diodes
T8S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
Q5_A, Q5_B, Q5_C, Q5_D, Q5_E, Q5_F,
Q5_G, Q5_H, Q6_A, Q6_B, Q6_C, Q6_D,
Q6_E, Q6_F, Q6_G, Q6_H, Q7_A, Q7_B,
Q7_C, Q7_D, Q7_E, Q7_F, Q7_G, Q7_H
PNP, -40V, MMBT4403, SOT23, FAIR-
CHILD
T582002690404
Q8 PMOS, 30V, AO3401A, SOT23, AOS T585001940446
Q9 NPN, 40V, LMBT3904LT1G, SOT23,
LRC
T581003460437
Reference Designator Description Vendor Part
Number
Note
U1 A\D, NCP303LSN29T1G, SOT23-5, ON-
SEMI
T611100025425
U2 DC-DC CONVERTER, LM3486MMX,
VSSOP, TI
T611700034922
U3, U4, U5 DC-DC, CONVERTER, TPS54202HD-
DCR, SOT-2, TI
T611700039022
U6 IC, REG, CJ7815, TO-252-2, JCET T610600099668
U7 IC, REG, CJ7915, TO-252-2, JCET T610600099768
U8 IC, DRIVER, TPS61169DCKR, SOT(5),
TI
T610900023502
U9 IC, SP, ADUM4160BRWZ, SOIC-16, ADI T610000059036
U10 IC, SP, TPS2051BDBVR, SOT-23(5), TI T610000054204
U11 MCU, LPC1837JBD144E, 144-LQFP,
NXP
T610300092808
U12, U13 IC, SP, TPD4S012DRYR, SON(6), TI T610000053904
U14 IC, MEMORY, SST26VF016B-104I\SM,
8-SOIJ, MICROCHIP
T610100071701
U15 IC, SP, TS5A623157DGSR, 10-VSSOP,
TI
T610000054304
U16, U17, U18, U19, U20, U21, U22, U23 LOGIC, NPIC6C596ADJ, 16-SO, NXP T612000037503
U24 MCU, ADSP-21489BSWZ-4B, 176-
LQFP, ADI
T610300092778
U25 IC, MEMORY, M12L128168A-6TG2N,
TSOP54, ESMT
T610100037642
U26 IC, SN74LVC125APW, TSSOP, TI T60A200125401
U27 IC, SP, MAX3283EAUT+T, SOT23,
MAXIM
T610000057770
U29 IC, SN74LVC1G17DCKR, SOT-25, TI T60A201G17501
U31 IC, PHOTO, 5V, EL817S1(C)(TA)-F, DIP,
EVERLIGHT
T58A000491533
U32 IC, A\D D\A, CS42528, LQFP-64, CIR-
RUS
T611500003506
U33, U34 A\D, CS5364, LQFP-48P, CIRRUS T611100023905
U35_A, U35_B, U35_C, U35_D, U35_E,
U35_F, U35_G, U35_H
OP-AMP, TL074C, SO-14, ST T610500023802
To Next Page
