31
ELECTRICAL PART LIST
Integrated Circuits (continued)
T8S Main PCB Assembly
Reference Designator Description Vendor Part
Number
Note
U36_A, U36_B, U36_C, U36_D, U36_E,
U36_F, U36_G, U36_H, U43, U52, U54,
U58, U60, U61, U62, U63, U64, U65, U53,
U55, U57, U59
IC, OP-AMP, NJM4580, SOP-8, JRC T610500010706
U56 IC, OP-AMP, TL072CDT, SO8, ST T610500028202
VR1_A, VR1_B, VR1_C, VR1_D, VR1_E,
VR1_F, VR1_G, VR1_H
VR, CA, 10K, C, 20X9.8MM, RV09ACF-
40-20F-10C10K-0068
T531230000119
VR17 VR, CA, 10K, B, 15.4X14X26,
XV014112YGPV26.4FR1B10K
T531220000216
VR9, VR10, VR11, VR12, VR13, VR14,
VR15, VR16, VR18
VR, CA, 10K, B, 15.4X14X24,
XV014112YGPV24FR1B10K
T531220000116
Miscellaneous
Reference Designator Description Vendor Part
Number
Note
F1, F2 FUSE, 30V, 200MA, 1206, 0ZC-
J0020FF2E
T690100003000 3
J1, J2, J3, J4, J5, J6, J7, J8 6.35MM STEREO JACK, NRJ6HF T710200009700
J9 USB SOCKET, 90, USB, AF, DIP-038-G T710200002400
J10 JACK, USB TYPE B, 319BF-K-C2-M-
BN, 4P
T710200009500
J11 6.35MM STEREO JACK WITH HALF
THREADED, NMJ6HHD2
T710200009800
J12 CONN, CF2014, .5MM HLD 1,
CF20141V0R0-NH
T690300062300
J14 HEADER, SMT, 2*5PIN, 1.27-2X5SW-
5.5B, 90
T690300079300
J15 HEADER, DUAL PIN, 14P, P2.54, 180,
GOLD, CCP254010-0714
T690300022200
P1, P3, P4 24P, P=2.0MM, 180, CH74242M100-0P T690300104100
P2 GP CONNECTOR, B4B-XH-A, 4 PIN, L,
CCN250000-0104
T690300029000
SW1 PUSHBUTTON SWITCH, PB-22E80-
S-E
T670100001700
SW2, SW3, SW4 ENCODER, RE12CF-41-20F-24P, 180 T670500001900
SW5 ENCODER, SDB161EPVB16.7FR-1-4-
12-12PC
T670500002000
T1 TRANSFORMER, 6.6V, 3.3V, 4PI, MU-
RATA, 78604\9C
T622000010300
T2 TRANSFORMER, 3.3V, 4PI, MURATA,
DA101C
T622000008300
Y1 CRYSTAL, 12MHZ, 20, SMD, TXC,
7M12000039
T690900008100
Y2 CRYSTAL, 12.288MH, SMD, SIWARD,
XTL571200-M13-105, SX-322
T690900008000
Y3 OSC, 11.28960, SMD, TXC,
7X11200002
T690900008400
To Next Page
