16 | EN
SETUP
Wallboard
Wood stud Metal stud
Wallboard
7.9mm (⁄in)
Wood stud/metal stud
4.8mm (⁄in)
4.8mm
(⁄in)
4.8mm
(⁄in)
WARNINGS:
Do not mount on surfaces that are not sturdy, or that have
hazards concealed behind them, such as electrical wiring or
plumbing. If unsure, please contact a professional installer.
The included hardware is not suitable for masonry surfaces.
d
7.9mm
(⁄in)
> 10mm (⅜in)
