Installation
Installation Procedures
First complete the electrical connections and then check for correctness.
Installation Opening
This unit can be installed in any dashboard Having an opening as shown below.
Insert mounting collar into the dashboard and bend the mounting tabs out with a screwdriver. Make sure that lock
lever is flush with the mounting collar( not projecting outward).
Connect all wiring harness and slide the head unit into the mounting collar until it clicks into place.
Wiring Connections
To Next Page
