14
Other Operations
1. AUX Input
The AUX Input Jack is a 3.5mm stereo jack on the front panel of the unit. Press
the Mode button to choose AUX. Connect any portable audio device such as a
MP3 player to unit. Use the volume control to adjust volume.
2. RCA Output
The RCA Output Jack is on the back of the unit. (Refer to Wiring Diagram)
This output is for connecting amplifier, equaliser, or other audio component that
requires a pre-amp out connection. (Red=Right, White=Left) Follow the manu-
factures instructions for the audio component that you are connecting.
3. Video Output
The video output Jack is on the back of the unit. (Refer to Wiring Diagram)
When the unit is on, press POW/TFT OFF button on the panel to switch off the
display. When the display is off, the video out signal will be available so that the
connected monitor will show the screen of the unit. Press this button again to
resume the image.
