20
BOSS HD Equalizer Tilt System
TROUBLE SHOOTING
If you have having operational problems with your power chair equipped with the Equalizer,
there are a few simple things you may want to have checked before contacting you equipment
provider.
1. Low power or short run time.
Make sure that the batteries are properly connected and have had a chance to fully charge.
Follow the charging instructions that come with the power base. If your batteries are older, the
charger may indicate that they are fully charged yet they may have low capacity.
2. Loose connections
There are a number of wiring connections used on the system. Some of them include those go-
ing to the motors, batteries, joystick, and tilt safety switches. If you notice that one of the con-
nections is loose, shut off the power to the unit and remake the loose connection.
3. Seating System is not functioning.
Check the unit has power.
Check that the seating system is not tilted/elevated beyond the Drive Lockout Angle.
Check cable/ cable tie connections.
Check/ Charge/ Replace Batteries.
3. Jerky operation while driving on a fl at surface.
Lower the angle of the seating system if tilted.
Refer to Powerbase/Wheelchair Owners Manual for further troubleshooting.
4. The unit comes to a complete stop while driving, requiring you to release the joystick be-
fore driving again. You may need to lower the angle of the seating system if you have it tilted.
NOTE: Refer to the Powerbase Owners Manual for troubleshooting powerbase issues.
For all other issues please refer to your dealer or call PaceSaver Service Department at
1-800-255-0285.
