Boss Infinity - Page 29

30
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B
C C D D
Parts List
DESCRIPTIONPART NUMBERQTYITEM
COMPR MTG SYS, INFINITY 45-60-150 SCI8G 0820035311 ELEC SYS, INFINITY 45-60-150 SCI8G 08200355-999 12 OIL-AIR-HYD CLNG SYS, INFINITY SCI8G 08200356-999 13 CANOPY SYS, INFINITY 45-60-150 SCI8G 0820035414
SHEET
20054-001
1 1
OF
REV
1
INFINITY 45-60 SCI8G 08
BOSS INDUSTRIES 1761 GENESIS DR. LA PORTE, IN 46350
N/A
PATH MATERIAL
G:\Inventor Files\20k\20054-001.dwg
12/3/2007 12/3/2007
DCL
DRAWN
NDD
CHECKED
1=4
D
DESCRIPTION
DWG NO
R
SCALE
SIZE
UNMACHINE D SURFACES
FRACTIONAL
`
1/16
DECIMAL
`
.03
ANGULAR
`
1°
DO NOT SCALE
TOLERANCES
UNLESS NOTED
MACHINED SURFACES
NOMINAL DIM.
0.000 TO 1.000
`
.010
1.001 TO 5.000
`
.015
5.001 TO 10.000
`
.020
10.001 & OV ER
`
.025
THIS DRAWING AND ALL ITS CONTENTS ARE PROPERTY OF BOSS INDUSTRIES, INC. AND MUST NOT BE COPIED OR MADE PUBLIC. IT IS LOANED AND IS SUBJECT TO RETURN UPON DEMAND. THE INFORMATION CONTAINED IN THIS DRAWING IS CONFID ENTIAL AND MUST NOT BE USED, DIRECTLY OR INDIRECTLY, IN ANY WAY DETRIMENTAL TO THE INTERES T OF BOSS INDUSTRIES, INC.
PROPRIETARY INFORMATION
34 3/4 in
[882.7 mm]
32 1/4 in
[819.2 mm]
17 3/4 in
[450.9 mm]
6 3/8 in
[163.2 mm]
5 in
[127.0 mm]
19 in
[481.4 mm]
20 1/4 in
[514.4 mm]
DIMENSIONS OF MOUNTING HOLES
REVISION HISTORY
REV DESCRIPTION DATE ENG
1
UPDATED 200353 TO REV 1, 200354 TO REV 1
5/22/2008 MCM
