Parts List
DESCRIPTIONPART NUMBERQTYITEM
BASE, FRAME INFINITY (REV 5)30239111
MOTOR, 1.58 CIR SAE "A" 3/4 ROUND SIDE PORT30166512
HUB, COUPLING 25MMX8X7 KYWYR28-02STL30210113
SPIDER, COUPLING R28-02 98SHR RED302103 14
HUB, COUPLING 3/4 ROUND W 3/16 KYWY R28-03STL
302455 15
WASHER, LOC 10MM938810-22086
CONNECTOR, 3/4 MJIC X -12 MSAE
970512-10617
ELBOW, HYD 1/2 MJIC X -10 MSAE970408-08818
BOLT, HEX GR8 3/8-16 X 1 1/2929806-15029
ELBOW, HYD 1/2 MBSPP X 1/2 MJIC
970608-050310
INDICATOR, AIR FLTR SRV 15H2O302428 111
PLUG, PIPE 1/8 BSPP HEX DRIVE
305624112
ADAPTER, 1/8 MBSPP X 1/8 FNPT970802-012213
NIPPLE, HYD HEX RED 1/4 X 1/8961604-012114
SWITCH, PRESSURE FURNAS
300904 115
ELBOW, PIPE 45° STREET 1/8960802-012116
AIREND, SCI8 3.69-1 RATIO INTEGRATED (REV 1)
301722-369117
ADAPTER, HYD MTR TO COMPR SCI8&8G (REV 2)302309 118
SWITCH, OPTIC LIQUID LEVEL 12VDC WET 1/4NPT307189119
ADAPTER, 1/2 MBSPP X 1/2 FNPT
970808-050120
BUSHING, RED 1/2 X 1/4 GAL907602-010121
NIPPLE, HYD HEX 1/8960402-012122
VALVE, MINI BALL 1/2 NPT302633123
FITTING, 1/2 FLEX-LOC PUSH-ON BARB X 1/2 MNPT307440224
CAP, PLASTIC 1/2 NPT
307439125
HOSE, 1/2 OIL DRAIN GRAY3026362 FT26
TEE, MB 1/8 F X 1/8 F X 1/8 M961902-012127
SWITCH, PRESS 3-WAY NO-NC 5PSI307198 128
ELBOW, 1/4 TUBE SWVL X 1/8 MNPT980704-012129
CONNECTOR, 1/2 JIC X 1/2 BSPP FS973108-050130
WASHER, FLAT 10MM938910-200
5
31
NUT, COALESCER (REV 4)300233 132
WASHER, LOC GR8 3/8
937806-094233
WASHER, FLAT GR8 3/8938206-071234
BOLT, HEX GR10.9 10MM X 25MM929210-250835
BRACKET, RELAY MTG (REV 7)302608136
DECAL, TEMP. COMPR.- 250 F301594137
DECAL, TEMP. HYD.-140 F30
301593138
ADAPTER, 1/2 MNPT X 1/2 FJIC307201 139
DECAL, DIRECTION OF ROTATION
300048140
WASHER, BRASS .585OD X .405ID X .070 THK
307203141
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET
200353
1 1
OF
REV
1
COMPR & MTG SYS, INFINITY 45/60/150 SCI8G
08
BOSS INDUSTRIES
1761 GENESIS DR.
LA PORTE, IN 46350
N/A
PATH
MATERIAL
G:\Inventor Files\200k\200353.dwg
11/19/2007
NDD
DRAWN
CHECKED
1=8
D
DESCRIPTION
DWG NO
R
SCALE
SIZE
UNMACHINE D SURFACES
FRACTIONAL
`
1/16
DECIMAL
`
.03
ANGULAR
`
1°
DO NOT SCALE
TOLERANCES
UNLESS NOTED
MACHINED SURFACES
NOMINAL DIM.
0.000 TO 1.000
`
.010
1.001 TO 5.000
`
.015
5.001 TO 10.000
`
.020
10.001 & OV ER
`
.025
THIS DRAWING AND ALL ITS
CONTENTS AR E PROPE RTY
OF BOSS INDUSTRIES, INC.
AND MUST NOT BE COPIED
OR MADE PUBLIC. IT IS
LOANED AND IS SUBJECT TO
RETURN UPON DEMAND. THE
INFORMATION CONTAINED IN
THIS DRAWING IS
CONFID ENTIAL AND MUST
NOT BE USED, DIRECTLY OR
INDIRECTLY, IN ANY WAY
DETRIMENTAL TO THE
INTEREST OF BOSS
INDUSTRIES, INC.
PROPRIETARY INFORMATION
1
31
6
35
10
30
10
21
19
39
20
37
10
13
16
14
15
28
27
29
13
11
22
31
17
18
36
2
7
38
9
33
34
8
5
4
3
35
6
17
32
12
23
40
41
24
24
25
REVISION HISTORY
REV DESCRIPTION DATE ENG
1
ADDED (2) 307440, (1) 307439. REMOVED (2)
302634, (1) 906030-020, (2) 300033-075.
302636 WAS 6".
5/22/2008 MCM
1
1
1
