22
Changing the Battery
If the display indicates “bt,” the battery has run low. Replace the
battery as described below.
* The use of an AC adaptor is recommended as the unit’s power
consumption is relatively high. Should you prefer to use
batteries, please use the alkaline type.
* Rechargeable Ni-MH batteries cannot be used.
* The contents of internal memory will not be lost when you
replace the battery, but we recommend that you make regular
backups (p. 14) for safety’s sake.
Thumbscrew
Battery Housing
Pedal
Spring Base
Coil Spring
Guide Bush Hole
Battery Snap Cord
Battery
Snap
9 V Battery
* Incorrect handling of batteries, rechargeable
batteries, or a battery charger can cause leakage,
overheating, re, or explosion. Before use, you must
read and strictly observe all of the precautions that
accompany the batteries, rechargeable batteries, or
battery charger.
1. Loosen the thumbscrew at the front of the pedal,
then lift the pedal upwards to open the unit.
* The thumbscrew can be left in the pedal while changing the
battery.
2. Remove the old battery from the battery housing,
and remove the battery snap connected to it.
3. Connect the battery snap to the new battery, and
place the battery inside the battery housing.
* Be sure to carefully observe the battery’s polarity (+ versus -).
4. Slip the coil spring onto the spring base on the back
of the pedal, then close the pedal.
* Carefully avoid getting the snap cord caught in the coil
spring.
5. Finally, insert the thumbscrew into the guide bush
hole and fasten it securely.
To Next Page
