2-20
190 Montauk
Section 2 • General Information
R
Canvas (Option)
Consult your Boston Whaler® dealer or check with
your owner’s manual before using any chemical
treatments on your canvas. To keep the canvas and
metal parts in good working condition and keep a
Canvas (Option)
Fig. 2.20.1
1
2
3
4
SUN TOP (BLACK OR BLUE)
FORWARD SUPPORT STRAPS DETAIL
SUN TOP PROPERLY STOWED IN BOOT
PEDESTAL SEAT COVER (BLACK OR BLUE)
CONSOLE COVER W/COOLER (OPTION)
(BLACK OR BLUE)*
5
1
2
3
5
5
The sun-top canvas must be secured in
the canvas boot before trailering. NEVER
TRAILER THE CANVAS SUN-TOP IN THE OPEN
POSITION.
NOTICE
* AVAILABLE WITHOUT COOLER COVER
*
REFER TO THE MANUFACTURER’S MANUAL IN
YOUR OWNER’S MANUAL PACKET FOR COMPLETE
INSTRUCTIONS, INFORMATION AND WARRANTY.
good appearance, you will need to keep them clean.
See page 5-5 of this manual for care and maintenance
instructions. Do not use bleach or solvents to clean
the canvas material.
Be sure to read and understand the safety rules for
recreational activities presented in Section 1, pages
1-13 thru 1-15 of this manual.
If equipped, the tow arch provides for recreational
skiing and wakeboarding.
Ski/Tow Arch (Option)
!
CAUTION
DO NOT USE THE SKI PYLON WITH ANY EQUIPMENT
WHICH IS TIED TO THE TOW ROPE!
If engaged in tubing or such other recreational towing, it
is recommended that you attach the tow rope to the stern
eyes at the transom of your boat.
The ski pylon is for skiing and/or wakeboarding ONLY.
Ski/Tow Arch (Option)
Fig. 2.20.2
1
2
TOW ARCH
SKI PYLON
1
! WARNING
146029
#1590140
SKI PYLON MUST BE SECURED WHEN IN USE
TOW ROPE MAY BACKLASH INTO COCKPIT
DO NOT USE TO TOW ITEMS THAT ARE ATTACHED
TO TOW ROPE SUCH AS TUBES OR OTHER TOWABLES
DO NOT USE SWIM PLATFORM WHEN ENGINE IS
RUNNING
2
