18
During loading, do not exceed the maximum loading data
for the carcass, tray base, drawers and workbenches.
Ensure that the load is evenly distributed.
3. Loading Data
WARNING
Cabinet/rack carcase up to system width 1300 mm 1.500 kg
Cabinet/rack carcase up to system width 1600 mm 1.000 kg
Hinged door cupboard for cases 800 kg
Suspended cabinets with hinged doors or lifting flap 150 kg
Maintenance trolley 300 kg
Tray base up to Cabinet/rack system width 1050 mm 100 kg
Tray base up to Cabinet/rack system width 1300 mm 160 kg
Shelf for hinged door cupboard for cases 75 kg
Shelf for suspended cabinets 50 kg
Partly extending drawers/trays Normal load 100 kg
Fully extending drawers/trays Normal load 75 kg
Fully extending drawers/trays Heavy load 200 kg
Drawers Maintenance trolley 40 kg
Roller tray set Normal load 300 kg
Roller tray set Heavy load 600 kg
Base with level adjustment 1.000 kg
Stacker base 1.000 kg
Cabinet support with roll edge 4-sides 200 kg
bott Boxes 1-2-90 4 kg
bott Boxes 1-3-165 / M3 8 kg
bott Boxes 2-3-165 / L3 10 kg
bott Boxes 1-4-165 / M4 10 kg
bott Boxes 2-4-165 / L4 12 kg
bott Boxes 2-5-165 / L5 14 kg
varioSafe (with rail / without rail VCA-03 / VCA-04) 15 kg
varioSlide (carry case / drawer open) 15 kg
varioSort - depth 440 mm 15 kg
Euroboxes 25 kg
When loading, always begin at the bottom; when unloading,
always begin at the top.
Always only open one drawer or tray at a time in system
cabinets and shelving systems.
The cabinets must never be loaded or unloaded using
transport and operating equipment.
Drawer cabinets/System cabinets
