100W Dimension
200W Dimension
FRONT
REAR
FRONT
78.8inch (2000mm)
25.4inch
(646mm)
Solar Panel Dimension
78.8inch (2000mm)
13.7inch
(348mm)
Tape
REAR
35.4inch (90mm), 12awg
35.4inch (90mm), 12awg
＋
－
＋
－
＋
－
＋
－
4
