BougeRV CIGS - Connection Methods; Series Connection; Parallel Connection

The panel can be wired in series to produce the desired
voltage output.
The solar panel can be wired in parallel to produce the desired
current output with the solar parallel connector.
6
+
-
+
-
+
+
-
-
3. Series Connection
4. Parallel Connection
