BougeRV CIGS - How To Use; Solar Off-grid System; Solar Power Station System

How To Use
Compatible with various types power stations
DC7909DC5525DC5521Anderson
-
+
Solar Extension Cable
Battery Cable
• First connect battery terminal wires to the charge controller.
• Then connect the solar panel to the charge controller.
+
-
+
-
1
2
2
(1) Peel off the protection tape
in order.
(2) Attach the solar panel to the
ground.
(Not included in the package)
As long as your other cable is equipped with MC4 connectors, then it could connect with our
connector of the solar panel.
Note: Connecting the power station does not need connecting with the solar charge controller.
1. Solar Off-grid System
2. Solar Power Station System
5
