128
7. Observe the cable routing from the Speed Sensor Magnet to the Servo
Motor wiring harness.
8. Disconnect the Speed Sensor Cable from the Servo Motor wiring
harness.
NOTICE: Do not touch the Potentiometer. Do not crimp any cables.
Speed Sensor
Magnet
Speed Sensor
Speed Sensor Cable
Servo Motor
Potentiometer
Speed Sensor Cable
Connection
