4.Usinga6mmhexwrenchanda13mmwrench,removetheindicated
hardware from the Lower Handlebar Arm and the Arm Pivot Rod. The
hardware on both ends of the Arm Pivot Rod will need to be held to
remove it.
5.SlightlypulltheHandlebarArmoffthemachinetoexposetheCable
Connections.
6. Disconnect the Handlebar Cable from the Upper Handlebar that goes
into the Console Mast.
7. Remove the Handlebar Arm from the machine.
8.Usinga6mmhexwrench,removethe4screws(twoindicated,twoon
othersideofHandlebar)fromtheUpperHandlebarArm.
9. Remove the Upper Handlebar Arm from the Lower Handlebar Arm.
10. Re-assemble the machine in the reverse order of when the parts were
removed.
Make sure the Upper Handlebar Arms are secure before you
exercise.
Handlebar Cable
Lower Handlebar Arm
Upper Handlebar Arm
11. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s
Manual.
