84
4.Usingtwo6mmhexwrenches,removetheindicatedhardwarefromthe
Lower Handlebar Arm and the Arm Pivot Rod. The hardware on both ends
of the Arm Pivot Rod will need to be held to remove it.
5.SlightlypulltheHandlebarArmoffthemachinetoexposetheCable
Connections.
6. Disconnect the Handlebar Cable from the Upper Handlebar that goes
into the Console Mast.
7. Remove the Handlebar Arm from the machine.
Handlebar Cable
Lower Handlebar Arm
Upper Handlebar Arm
Interior Pivot Cover
